XJDK-00123
XJDK-00124
XJDK-00122
MAIN PUMP
2
5
13
27
31
40
40
44
49
49
56
60
61
62
65
66
67
68
69
70
71
72
Позиция на иллюстрации
Заводской номер детали
Название детали
XJDK-00123
XJDK-00123
SEAL KIT
XJDK-00124
XJDK-00124
GEAR PUMP
XJDK-00122
XJDK-00122
CYLINDER BARREL KIT
MAIN PUMP
MAIN PUMP
MAIN PUMP
2
BODY-H
BODY-H
5
PLATE-VALVE
PLATE-VALVE
13
PACKING
PACKING
27
PIN
PIN
31
BEARING-NEEDLE
BEARING-NEEDLE
40
O-RING
O-RING
44
SCREW
SCREW
49
PLUG
PLUG
56
PIN-SPRING
PIN-SPRING
60
SCREW
SCREW
61
NUT
NUT
62
WASHER-SEAL
WASHER-SEAL
65
PUMP-GEAR
PUMP-GEAR
66
COUPLING
COUPLING
67
COLLAR
COLLAR
68
SCREW
SCREW
69
O-RING
O-RING
70
WASHER
WASHER
71
O-RING
O-RING
72
O-RING
O-RING
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
