Каталог запасных частей к технике: Hyundai R16-9. MAIN CONTROL VALVE (3/3)
XJCK-00476
XJCK-00110
XJCK-00001
XJCK-00001
XJCK-00003
XJCK-00329
XJCK-00330
XJCK-00331
XJCK-00332
XJCK-00333
XJCK-00293
XJCK-00329
XJCK-00335
XJCK-00308
XJCK-00308
XJCK-00307
XJCK-00306
XJCK-00305
XJCK-00305
XJCK-00304
XJCK-00001
XJCK-00303
XJCK-00302
XJCK-00308
XJCK-00308
XJCK-00484
XJCK-00339
MAIN CONTROL VALVE
XJCK-00308
XJCK-00308
XJCK-00481
XJCK-00302
XJCK-00303
XJCK-00001
XJCK-00304
XJCK-00305
XJCK-00305
XJCK-00306
XJCK-00307
XJCK-00373
XJCK-00328
XJCK-00480
XJCK-00307
XJCK-00306
XJCK-00305
XJCK-00305
XJCK-00331
XJCK-00001
XJCK-00330
XJCK-00334
9
10
11
12
15
15
15
17
17
17
17
18
18
18
19
20
21
25
101
102
103
104
105
106
107
108
109
110
111
112
112
113
114
115
116
117
118
119
120
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| XJCK-00476 | XJCK-00476 | Spool Assy | |
| XJCK-00110 | XJCK-00110 | O-RING | |
| XJCK-00001 | XJCK-00001 | O-Ring | |
| XJCK-00003 | XJCK-00003 | PLUG | |
| XJCK-00329 | XJCK-00329 | Poppet | |
| XJCK-00330 | XJCK-00330 | Spring | |
| XJCK-00331 | XJCK-00331 | Plug | |
| XJCK-00332 | XJCK-00332 | O-RING | |
| XJCK-00333 | XJCK-00333 | PLUG | |
| XJCK-00293 | XJCK-00293 | O-Ring | |
| XJCK-00329 | XJCK-00329 | Poppet | |
| XJCK-00335 | XJCK-00335 | PLUG | |
| XJCK-00308 | XJCK-00308 | Bolt-S/Hd W/Washer | |
| XJCK-00307 | XJCK-00307 | Cover-Pilot | |
| XJCK-00306 | XJCK-00306 | Cover-Pilot | |
| XJCK-00305 | XJCK-00305 | O-Ring | |
| XJCK-00304 | XJCK-00304 | Plug | |
| XJCK-00001 | XJCK-00001 | O-Ring | |
| XJCK-00303 | XJCK-00303 | Spring | |
| XJCK-00302 | XJCK-00302 | Poppet | |
| XJCK-00308 | XJCK-00308 | Bolt-S/Hd W/Washer | |
| XJCK-00484 | XJCK-00484 | SPOOL ASSY | |
| XJCK-00339 | XJCK-00339 | BODY-WORK | |
| MAIN CONTROL VALVE | MAIN CONTROL VALVE | MAIN CONTROL VALVE | |
| XJCK-00308 | XJCK-00308 | Bolt-S/Hd W/Washer | |
| XJCK-00481 | XJCK-00481 | SPOOL ASSY | |
| XJCK-00302 | XJCK-00302 | Poppet | |
| XJCK-00303 | XJCK-00303 | Spring | |
| XJCK-00001 | XJCK-00001 | O-Ring | |
| XJCK-00304 | XJCK-00304 | Plug | |
| XJCK-00305 | XJCK-00305 | O-Ring | |
| XJCK-00306 | XJCK-00306 | Cover-Pilot | |
| XJCK-00307 | XJCK-00307 | Cover-Pilot | |
| XJCK-00373 | XJCK-00373 | BODY-WORK | |
| XJCK-00328 | XJCK-00328 | BODY-WORK | |
| XJCK-00480 | XJCK-00480 | BODY-WORK | |
| XJCK-00307 | XJCK-00307 | Cover-Pilot | |
| XJCK-00306 | XJCK-00306 | Cover-Pilot | |
| XJCK-00305 | XJCK-00305 | O-Ring | |
| XJCK-00331 | XJCK-00331 | Plug | |
| XJCK-00001 | XJCK-00001 | O-Ring | |
| XJCK-00330 | XJCK-00330 | Spring | |
| XJCK-00334 | XJCK-00334 | O-RING | |
| 9 | XJCK-00478 | TRAVEL WORK BLOCK | |
| 10 | XJCK-00479 | BOOM WORK BLOCK | |
| 11 | XJCK-00284 | BOOM LOCK VALVE | |
| 12 | XJCK-00483 | BUCKET WORK BLOCK | |
| 15 | XJCK-00488 | Overload Relief Valve | |
| 17 | XJCK-00290 | O-Ring | |
| 18 | XJCK-00291 | O-Ring | |
| 19 | XJCK-00292 | O-Ring | |
| 20 | XJCK-00096 | O-Ring | |
| 21 | XJCK-00009 | O-RING | |
| 25 | XJCK-00489 | Anticavitation Valve | |
| 101 | XJCK-00309 | COVER-LOCK VALVE | |
| 102 | XJCK-00310 | LOCK VALVE | |
| 103 | XJCK-00311 | SEAL | |
| 104 | XJCK-00312 | FILTER | |
| 105 | XJCK-00313 | SPECER | |
| 106 | XJCK-00314 | RING-RETAINING | |
| 107 | XJCK-00315 | SPRING A-LOCK VALVE | |
| 108 | XJCK-00316 | SPRING SEAT | |
| 109 | XJCK-00317 | PIN | |
| 110 | XJCK-00318 | POPET | |
| 111 | XJCK-00319 | RING-RETAINING | |
| 112 | XJCK-00010 | O-Ring | |
| 113 | XJCK-00321 | GUIDE-PISTON | |
| 114 | XJCK-00322 | PISTON-A1 | |
| 115 | XJCK-00323 | PISTON-B | |
| 116 | XJCK-00190 | O-RING | |
| 117 | XJCK-00324 | CONNECTOR | |
| 118 | XJCK-00325 | BALL-STEEL | |
| 119 | XJCK-00326 | PLUG | |
| 120 | XJCK-00327 | BOLT-HEX.SOCKET HEAD |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
