Каталог запасных частей к технике: Hyundai R16-9. AIR INTAKE & EXHAUST SYSTEM
11MJ-20021
XJAF-02699
XJAF-01587
XJAF-02743
XJAF-02744
S205-08300B
11MJ-20020
11MJ-20030
S035-082026
S411-080006
S403-082006
11M6-56130
11M6-56120
1
2
3
3
4
4
5
6
7
8
9
10
11
11
12
13
14
15
15
15
16
16
16
17
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 11MJ-20021 | 11MJ-20021 | Muffler Assy | |
| XJAF-02699 | XJAF-02699 | Element-Safety | |
| XJAF-01587 | XJAF-01587 | Element-Outer | |
| XJAF-02743 | XJAF-02743 | Vacuator-Valve | |
| XJAF-02744 | XJAF-02744 | Cap | |
| S205-08300B | S205-08300B | Nut-Hex | |
| 11MJ-20020 | 11MJ-20020 | Muffler Wa | |
| 11MJ-20030 | 11MJ-20030 | Bracket | |
| S035-082026 | S035-082026 | BOLT-W/WASHER | |
| S411-080006 | S411-080006 | WASHER-SPRING | |
| S403-082006 | S403-082006 | WASHER-PLAIN | |
| 11M6-56130 | 11M6-56130 | Saddle | |
| 11M6-56120 | 11M6-56120 | U-Bolt | |
| 1 | XJAF-02742 | Air Cleaner | |
| 2 | 11MJ-20010 | Muffler Sub Assy | |
| 3 | XJAF-02049 | Hose-Air | |
| 4 | S572-530006 | Clamp-Hose, Wire Type | |
| 5 | S572-570006 | Clamp-Hose, Wire Type | |
| 6 | 11MJ-20100 | Pipe-Tail | |
| 7 | 11M6-56060 | U-Clamp | |
| 8 | S035-102526 | Bolt-W/Washer | |
| 9 | S037-102526 | BOLT-W/WASHER | |
| 10 | XJAF-02037 | Elbow | |
| 11 | XJAF-01551 | Gasket | |
| 12 | XJAF-01987 | Stud | |
| 13 | XJAF-01985 | Stud | |
| 14 | XJAF-01986 | Stud | |
| 15 | XJAF-02201 | Nut | |
| 16 | XJAF-02002 | Washer-Spring | |
| 17 | XJAF-01998 | Washer-Plain |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
