Позиция на иллюстрации
Заводской номер детали
Название детали
1
21EN-32300
Accel Actuator
2
11Q3-60010
Lever
3
11Q3-60000
Bracket
4
S015-060156
BOLT-HEX
5
S035-082016
Bolt-W/Washer
6
S205-081006
Nut-Hex
7
S441-06000B
Washer-Hardened
8
S411-080006
WASHER-SPRING
9
S593-000902
CLIP-HARNESS
10
S037-102026
BOLT-W/WASHER
11
11EM-02030
Spacer
12
S035-084026
Bolt-W/Washer
13
11M6-53150
Clamp-Tube,Single
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
