Каталог запасных частей к технике: Hyundai R140W-9S. DOZER BLADE-REAR
Y020-055511
Y020-055511
Y020-055511
Y020-055511
S652-810002
51Q4-51410
51Q4-51410
51Q4-51410
51Q4-51410
S651-810002
S651-810002
S037-122556
S037-122556
S037-122556
S037-122556
1
1-1
1-2
1-3
1-4
1-4-2
1-4-2
1-4-3
1-4-3
1-4-3
1-4-3
1-4-4
1-4-4
1-5
1-5-2
1-5-2
1-6
1-7
1-8
1-9
1-10
1-10
1-11
1-11
1-12
1-13
1-13
1-14
1-14
1-15
1-16
1-17
1-18
1-18
1-19
1-19
2
2
3
3
5
5
5
5
6
6
9
10
11-1
11-1
11-2
11-2
12
12
1-4-1
1-5-1
11
11
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| Y020-055511 | Y020-055511 | Seal-Dust,Dli,Kpu | |
| S652-810002 | S652-810002 | Nipple-Grease | |
| 51Q4-51410 | 51Q4-51410 | Plate-Lock | |
| S651-810002 | S651-810002 | NIPPLE-GREASE | |
| S037-122556 | S037-122556 | BOLT-W/WASHER | |
| 1 | 58Q4-51001 | Blade Assy | |
| 1-1 | 58Q4-51011 | Blade Wa | |
| 1-2 | 51Q4-51252 | Bracket Wa-Lh | |
| 1-3 | 51Q4-51262 | Bracket Wa-Rh | |
| 1-4 | 51Q4-50311 | Link Assy | |
| 1-4-2 | 51Q4-55010 | Bushing | |
| 1-4-3 | Y020-055511 | Seal-Dust,Dli,Kpu | |
| 1-4-4 | S652-810002 | Nipple-Grease | |
| 1-5 | 51Q4-50330 | Link Assy | |
| 1-5-2 | 51Q4-55000 | Bushing | |
| 1-6 | 51Q4-50210 | Washer-Lock | |
| 1-7 | 51N4-55321 | Pin Assy | |
| 1-8 | 51N4-55311 | Pin Assy | |
| 1-9 | 53N4-55330 | Pin Assy | |
| 1-10 | 51Q4-51410 | Plate-Lock | |
| 1-11 | S391-055095 | Shim-Round | |
| 1-12 | S392-055095 | Shim-Round | |
| 1-13 | S651-810002 | NIPPLE-GREASE | |
| 1-14 | S037-122556 | BOLT-W/WASHER | |
| 1-15 | S017-120406 | Bolt-Hex | |
| 1-16 | S441-12000B | WASHER-HARDENED | |
| 1-17 | 51Q4-55320 | Pin Assy | |
| 1-18 | S017-161206 | Bolt-Hex | |
| 1-19 | S205-16100B | NUT-HEX | |
| 2 | 51Q4-55440 | Pin Assy | |
| 3 | 53N4-55450 | Pin Assy | |
| 5 | S391-065110 | Shim-Round | |
| 6 | S392-065110 | Shim-Round | |
| 9 | S018-24050D | Bolt-Hex | |
| 10 | S441-240006 | WASHER-HARDENED | |
| 11-1 | 51Q4-51150 | Bracket-Reflector | |
| 11-2 | 51EK-52990 | Reflector-Rear | |
| 12 | S091-100206 | Bolt-Wing | |
| 1-4-1 | 51Q4-50321 | Link Wa | |
| 1-5-1 | 51Q4-50340 | Link Wa | |
| 11 | 51Q4-51140 | Reflector Assy |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
