9245615
9245616
00
00
01
02
02
03
03A
03B
03B
05
05
06
06
07
07
101
102
102
Позиция на иллюстрации
Заводской номер детали
Название детали
9245615
9245615
IDLER ASSY
9245616
9245616
IDLER ASSY
00
1032661
BRG.
01
3077237
АХLЕ
02
A810080
O-RING
03
9245617
IDLER
03A
7047467
IDLER
03B
3103740
BUSHING
05
4138084
РIN
06
4282633
SEAL, GROUP
07
4315607
PLUG
101
1023479
YОКЕ
102
J901640
BOLT
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
