02
02
02
06
07
07
07A
07A
08
08A
08A1
08A1
08A1A
08A2
08A3
08A4
08A5
08A6
08A7
08A8
08A8
08A9
08A10
08A10
08A11
08A11
08B
08C
08D
Позиция на иллюстрации
Заводской номер детали
Название детали
02
J260816
BOLT, SEMS
02A
J900816
BOLT
02B
А590108
WASHER, PLANE
06
J460614
SCREW, SEMS
07
1027579
HARNESS, WIRE
07A
4456778
DIODE
08
4488903
MONITOR
08A
4646113
MONITOR
08A1
4646114
METER
08A1A
4426362
LAMP
08A2
4483028
CASE
08A3
4482980
BOARD, PRINTED
08A4
4482601
CASE
08A5
4482602
BRACKET
08A6
4482603
BUZZER
08A7
4482604
SCREW, TAPPING
08A8
4482973
SCREW, TAPPING
08A9
4388962
SCREW
08A10
4482973
SCREW, TAPPING
08A11
4426370
SCREW
08B
4426353
COVER
08C
J680412
SCREW, SEMS
08D
4482976
BRACKET
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
