4456244
01
02
03
04
05
05A
05B
06
07
07A
07B
Позиция на иллюстрации
Заводской номер детали
Название детали
4456244
4456244
CATCH, DOOR ASSY
01
4456245
CATCH, DOOR
02
4456246
CASE ASSY
03
4456247
RUBBER, STOPPER
04
4089012
CAP
05
J260820
BOLT, SEMS
05A
J900820
BOLT
05B
А590108
WASHER, PLANE
06
4456248
STOPPER
07
J271025
BOLT, SEMS
07A
J901025
BOLT
07B
J222010
WASHER
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
