Каталог запасных частей к технике: Hitachi ZX-160W. OIL TANK
00
01
02
03
05
12
13
16
16A
16B
16C
16C
16C
18
19
19A
20
21
22
22A
24
24A
24B
24C
24D
24E
25
25A
26
26A
26B
26C
26D
26E
27
28
30
31
32
34
40
40A
42
42A
44
44
44A
44A
46
46A
51
51A
52
52A
54
55
56
57
57A
58
58A
59
59A
60
60A
61
61A
62
62A
63
63A
64
64A
65
65A
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 00 | 5008045 | TANK, OIL | |
| 01 | А590916 | WASHER, SPRING | |
| 02 | J222016 | WASHER | |
| 03 | J921640 | BOLT | |
| 05 | 997330 | O-RING | |
| 12 | А810160 | O-RING | |
| 13 | А810060 | O-RING | |
| 16 | 4424867 | FILTER, SUCTION | |
| 16A | 4285577 | STRAINER | |
| 16B | 4454418 | ROD | |
| 16C | J950010 | NUT | |
| 18 | 449558 | WASHER, SEAL | |
| 19 | 8053499 | GAUGE, LEVEL | |
| 19A | 4100967 | BOLT | |
| 20 | 4250260 | SENSOR | |
| 21 | 4250261 | GASKET | |
| 22 | А885002 | PLUG | |
| 22A | 957366 | O-RING | |
| 24 | 4434017 | BREATHER, AIR | |
| 24A | 4437833 | BODY | |
| 24B | 4437838 | ELEMENT | |
| 24C | 4437837 | COVER | |
| 24D | 4371825 | NUT | |
| 24E | 4437836 | CAP | |
| 25 | А885008 | PLUG | |
| 25A | 4506429 | O-RING | |
| 26 | 9184556 | COVER | |
| 26A | 4408661 | BRACKET | |
| 26B | 1025093 | COVER | |
| 26C | 4350623 | BOLT | |
| 26D | 4225466 | WASHER, SPRING | |
| 26E | 4225472 | WASHER, PLANE | |
| 27 | J021025 | BOLT, SEMS | |
| 28 | J770616 | BOLT, SOCKET | |
| 30 | 4443596 | ELEMENT, FILTER | |
| 31 | 4444482 | SPRING | |
| 32 | 4443782 | COVER | |
| 34 | J021025 | BOLT, SEMS | |
| 40 | А852334 | ELBOW, S | |
| 40A | 4509180 | O-RING | |
| 42 | А852422 | TEE, S | |
| 42A | 957366 | O-RING | |
| 44 | А852433 | TEE, S | |
| 44A | 4509180 | O-RING | |
| 46 | А852333 | ELBOW, S | |
| 46A | 4509180 | O-RING | |
| 51 | А885002 | PLUG | |
| 51A | 957366 | O-RING | |
| 52 | А852133 | ADAPTER, S | |
| 52A | 4509180 | O-RING | |
| 54 | 4479355 | FILTER, SUCTION | |
| 55 | J020825 | BOLT, SEMS | |
| 56 | А810070 | O-RING | |
| 57 | А852222 | ELBOW, S | |
| 57A | 957366 | O-RING | |
| 58 | А852322 | ELBOW, S | |
| 58A | 957366 | O-RING | |
| 59 | А852233 | ELBOW, S | |
| 59A | 4509180 | O-RING | |
| 60 | А852122 | ADAPTER, S | |
| 60A | 957366 | O-RING | |
| 61 | А852134 | ADAPTER, S | |
| 61A | 4509180 | O-RING | |
| 62 | А885003 | PLUG | |
| 62A | 4509180 | O-RING | |
| 63 | А852232 | ELBOW, S | |
| 63A | 4509180 | O-RING | |
| 64 | А852344 | ELBOW, S | |
| 64A | 4506418 | O-RING | |
| 65 | А853386 | ELBOW, S | |
| 65A | 4506429 | O-RING |
