Каталог запасных частей к технике: Hitachi ZX-160W. ELECTRIC PARTS (E)
00
01
02
04
05
05
07
07A
07B
07C
07D
07E
07F
07G
07H
07H
071
071
07J
07К
10
10
10
12
14
15
18
20
21
24
24
26
26
28
28
30
30
32
32
32
32
33
33
33
33
34
34
34
34
35
35
35
35
36
39
39
39
39
39
39
39
40
41
41
43
43
43
44
44
44
45
45
46
46
47
48
52
54
56
56
56
56
56
57
57
57
57
57
57
57
58
58
61
61
62
62
63
64
64
65
66
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 00 | SWITCH | WORKING LAMP SWITCH | |
| 01 | 3087882 | BRACKET | |
| 02 | 4361800 | SCREW, TAPPING | |
| 04 | 4462381 | BOX, SWITCH | |
| 05 | J010814 | BOLT, SEMS | |
| 07 | 0004429 | HARNESS, WIRE | |
| 07A | 4456778 | DIODE | |
| 07B | 4611526 | DIODE | |
| 07C | 4611527 | DIODE | |
| 07D | 4428910 | FUSE | |
| 07E | 4428911 | FUSE | |
| 07F | 4438015 | FUSE | |
| 07G | 4436736 | FUSE | |
| 07H | 4456735 | BOX, FUSE | |
| 071 | 4436737 | PULLER | |
| 07J | 4466497 | COVER | |
| 07К | 4604473 | COVER | |
| 10 | 4121859 | CLIP, BAND | |
| 12 | J460620 | SCREW, SEMS | |
| 14 | 4359384 | SWITCH | |
| 15 | 4367375 | BRACKET | |
| 18 | 4439897 | HARNESS, WIRE | |
| 20 | 4452160 | CONTROLLER | |
| 21 | J460616 | SCREW, SEMS | |
| 24 | 8082329 | BRACKET | |
| 26 | М430660 | SCREW | |
| 28 | А590106 | WASHER, PLANE | |
| 30 | J020816 | BOLT, SEMS | |
| 32 | 4281293 | HARNESS, WIRE | |
| 33 | J901016 | BOLT | |
| 34 | А590910 | WASHER, SPRING | |
| 35 | А590110 | WASHER, PLANE | |
| 36 | 4190261 | CLIP | |
| 39 | 4055312 | CLIP, BAND | |
| 40 | 4055311 | CLIP, BAND | |
| 41 | J460510 | SCREW, SEMS | |
| 43 | 4414207 | RELAY | |
| 44 | J460614 | SCREW, SEMS | |
| 45 | 4428213 | UNIT | |
| 46 | J460614 | SCREW, SEMS | |
| 47 | 4413974 | FLASHER | |
| 48 | J460614 | SCREW, SEMS | |
| 52 | 9759327 | BRACKET | |
| 54 | J011025 | BOLT, SEMS | |
| 56 | 4190274 | CLIP | |
| 57 | J011020 | BOLT, SEMS | |
| 58 | 4190261 | CLIP | |
| 61 | J460620 | SCREW, SEMS | |
| 62 | J460310 | SCREW, SEMS | |
| 63 | 4190291 | CLIP | |
| 64 | 4449019 | CLIP | |
| 65 | 4381572 | SCREW | |
| 66 | 4426354 | CAP |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
