9231302
9231303
4609691
4360347
4609692
3
4
5
6
8
11
13
14
15
16
Позиция на иллюстрации
Заводской номер детали
Название детали
9231302
9231302
ADJUSTER ASSY
9231303
9231303
CYL.ASSY
4609691
4609691
CYL
4360347
4360347
O-RING
4609692
4609692
ROD
3
4609693
SPACER
4
4609694
SPRING
5
4609695
WASHER
6
4609696
ROD, PISTON
8
4609697
PACKING, U-RING
11
4609698
SEAL, DUST
13
4609699
HOLDER
14
4609700
NUT
15
4609701
PLUG
16
4609702
VALVE
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
