Каталог запасных частей к технике: Hitachi ZAXIS 870H-3. PUMP, PISTON
01
011
011A
011B
014
014A
014B
030
030A
030B
111
123
124
127
130
153
156
157
211
251
261
263
271
312
325
401
403
406
408
466
468
490
490
490
491
492
530
530A
530B
532
534
535
702
706
710
717
717
719
724
724
725
725
725
728
732
774
789
792
808
808
824
885
887
887
901
953
954
981
983
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 4635645 | 4635645 | PUMP,PISTON | |
| 01 | 4661507 | PUMP,REGULATOR | |
| 011 | 0718001 | PISTON ASS’Y | |
| 011A | PISTON | PISTON | |
| 011B | SHOE | SHOE | |
| 014 | 0703002 | CYL. ASS’Y | |
| 014A | BLOCK;CYL. | BLOCK,CYL. | |
| 014B | PLATE,VALVE | PLATE,VALVE | |
| 030 | 0716801 | PLATE ASS’Y | |
| 030A | PLATE | PLATE | |
| 030B | BUSHING | BUSHING | |
| 111 | 0682301 | SHAFT,DRIVE | |
| 123 | 0682302 | BRG.,ROL. | |
| 124 | 0682303 | BRG.,NEEDLE | |
| 127 | 0339809 | SPACER | |
| 130 | 0682304 | BOOSTER | |
| 153 | 0718002 | RETAINER | |
| 156 | 0828401 | BUSHING | |
| 157 | 0682307 | SPRING | |
| 211 | 0682309 | PLATE | |
| 251 | 0981101 | SUPPORT | |
| 261 | 0682311 | COVER | |
| 263 | 0981102 | COVER | |
| 271 | 0981103 | CASING | |
| 312 | 0682314 | COVER | |
| 325 | 0682315 | COVER | |
| 401 | 0682316 | BOLT,SOCKET | |
| 403 | 0111530 | BOLT,SOCKET | |
| 406 | M340820 | BOLT, SOCKET | |
| 408 | 0102411 | BOLT, SOCKET | |
| 466 | 0236014 | PLUG | |
| 468 | 0175233 | PLUG | |
| 490 | 0263019 | PLUG | |
| 491 | 0451027 | SCREW | |
| 492 | 0451028 | PLUG | |
| 530 | 0800706 | PIN ASS’Y | |
| 530A | PIN | PIN | |
| 530B | PIN | PIN | |
| 532 | 0800707 | PISTON,SERVO | |
| 534 | 0682319 | STOPPER | |
| 535 | 0682320 | STOPPER | |
| 702 | 4292386 | O-RING | |
| 706 | 0443413 | O-RING | |
| 710 | 0682321 | O-RING | |
| 717 | 0682322 | O-RING | |
| 719 | 0682323 | O-RING | |
| 724 | 0443801 | O-RING | |
| 725 | 4297379 | O-RING | |
| 728 | 0443408 | O-RING | |
| 732 | 0682324 | O-RING | |
| 774 | 0682325 | SEAL,OIL | |
| 789 | 0682326 | RING,BACK-UP | |
| 792 | 0682327 | RING,BACK-UP | |
| 808 | 0451038 | NUT | |
| 824 | 960323 | RING, RETAINING | |
| 885 | 0313404 | PIN | |
| 887 | 4144353 | PIN,SPRING | |
| 901 | 0134458 | BOLT, EYE | |
| 953 | 0339847 | SCREW | |
| 954 | 0682328 | SCREW, SET | |
| 981 | PLATE | PLATE | |
| 983 | 0625509 | PIN |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
