Каталог запасных частей к технике: Hitachi ZAXIS 870H-3. MOTOR, OIL (2/2)
2
2-1
2-1
2-2
2-2
2-2
2-2-1
2-2-2
2-2-3
2-2-3
2-2-4
2-2-4
2-2-5
2-2-5
2-3
2-3
2-4
2-4
2-5
2-5
2-6
2-6
2-6-1
2-6-1
2-6-5
2-6-5
2-6-6
2-6-6
2-7
2-7
2-7-1
2-7-2
2-7-3
2-7-4
2-7-5
2-7-6
2-7-7
2-7-8
2-7-9
2-7-10
2-7-11
2-7-12
2-7-13
2-7-14
2-7-15
2-7-16
2-7-16
2-7-17
2-7-17
2-9
2-9
2-11
2-11
2-11
2-13
2-14
2-15
2-15
2-17
2-19
2-19
2-20
2-20
2-21
2-21
2-22
2-22
2-23
2-23
2-24
2-24
2-25
2-25
2-25
2-26
2-26
2-26
2-27
2-28
2-28
2-28
16
26
27
33
51
52
400
KIT,SEAL
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 4636857 | 4636857 | MOTOR,OIL | |
| 2 | PLATE ASS’Y | PLATE ASS’Y | |
| 2-1 | PLATE | PLATE | |
| 2-2 | SPOOL ASS’Y | SPOOL ASS’Y | |
| 2-2-1 | SPOOL | SPOOL | |
| 2-2-2 | VALVE,CHECK | VALVE,CHECK | |
| 2-2-3 | SPRING | SPRING | |
| 2-2-4 | PLUG | PLUG | |
| 2-2-5 | O-RING | O-RING | |
| 2-3 | 0163601 | SEAT, SPRING | |
| 2-4 | 0420002 | SPRING | |
| 2-5 | 0809601 | SEAT SPRING | |
| 2-6 | 0981701 | CAP ASS’Y | |
| 2-6-1 | CAP | CAP | |
| 2-6-5 | O-RING | O-RING | |
| 2-6-6 | BOLT,SOCKET | BOLT,SOCKET | |
| 2-7 | 0806602 | VALVE RELIEF | |
| 2-7-1 | SEAT | SEAT | |
| 2-7-2 | HOUSING,RELIEF | HOUSING,RELIEF | |
| 2-7-3 | POPPET | POPPET | |
| 2-7-4 | SEAT,SPRING | SEAT, SPRING | |
| 2-7-5 | SPRING | SPRING | |
| 2-7-6 | PLUG | PLUG | |
| 2-7-7 | GUIDE,SPRING | GUIDE, SPRING | |
| 2-7-8 | SCREW,SET | SCREW, SET | |
| 2-7-9 | NUT,LOCK | NUT,LOCK | |
| 2-7-10 | PISTON | PISTON | |
| 2-7-11 | O-RING | O-RING | |
| 2-7-12 | O-RING | O-RING | |
| 2-7-13 | O-RING | O-RING | |
| 2-7-14 | O-RING | O-RING | |
| 2-7-15 | RING,BACK-UP | RING, BACK-UP | |
| 2-7-16 | RING,BACK-UP | RING, BACK-UP | |
| 2-7-17 | RING,BACK-UP | RING, BACK-UP | |
| 2-9 | SPOOL | SPOOL | |
| 2-11 | ORIFICE | ORIFICE | |
| 2-13 | 0820203 | SPRING | |
| 2-14 | 0671002 | PLUG | |
| 2-15 | 4506418 | O-RING | |
| 2-17 | 0820204 | PLUG | |
| 2-19 | 0352304 | VALVE, CHECK | |
| 2-20 | 0352305 | SPRING | |
| 2-21 | 0352306 | PLUG | |
| 2-22 | 4506429 | O-RING | |
| 2-23 | ORIFICE | ORIFICE | |
| 2-24 | ORIFICE | ORIFICE | |
| 2-25 | 0436608 | PLUG | |
| 2-26 | 957366 | O-RING | |
| 2-27 | PLUG | PLUG | |
| 2-28 | PLUG | PLUG | |
| 16 | 0682803 | PIN | |
| 26 | 0809604 | SPRING | |
| 27 | 0251319 | PIN | |
| 33 | 0168008 | BOLT SOCKET | |
| 51 | NAME-PLATE | NAME-PLATE | |
| 52 | SCREW,DRIVE | SCREW, DRIVE | |
| 400 | 0979103 | PLATE,ASS’ Y | |
| KIT,SEAL | KIT,SEAL | KIT,SEAL |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
