Каталог запасных частей к технике: Hitachi LX-130-7. AIR CONDITIONER (1/2)
1
2
3
4
5
6
7
8
9
10
10
11
11
12
12
13
14
14
15
16
16
17
18
19
20
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
50
51
51
52
53
54
55
56
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 26756-71091 | AIR CONDITIONER UNIT | |
| 2 | 01183-10020 | BOLT&WASHER | |
| 3 | 02000-00010 | WASHER | |
| 4 | 26756-76031 | HOSE, DRAIN | |
| 5 | 26756-75571 | TUBE | |
| 6 | 26756-75581 | TUBE | |
| 7 | 26752-42511 | PLATE | |
| 8 | 26756-75791 | RUBBER | |
| 9 | 01183-10016 | BOLT&WASHER | |
| 10 | 26602-42031 | CLIP | |
| 11 | 26602-42101 | CLIP | |
| 12 | 26602-42091 | CLIP | |
| 13 | 26702-42341 | SPACER | |
| 14 | 01183-10020 | BOLT&WASHER | |
| 15 | 01183-10040 | BOLT&WASHER | |
| 16 | 01401-00010 | NUT | |
| 17 | 26756-75771 | HOSE | |
| 18 | 26756-75611 | TUBE | |
| 19 | 26756-75621 | TUBE | |
| 20 | 24067-62261 | CLIP | |
| 21 | 26756-75631 | GROMMET | |
| 22 | 03510-15075 | SPONGE | |
| 23 | 03510-15060 | SPONGE | |
| 24 | 29189-42031 | FILTER | |
| 25 | 26426-73481 | PLATE | |
| 26 | 26907-52401 | BOLT, WING | |
| 27 | 26676-72231 | DUCT | |
| 28 | 26676-72241 | RUBBER | |
| 29 | 01183-08016 | BOLT&WASHER | |
| 30 | 26676-70221 | BASE, SEAT | |
| 31 | 01183-10020 | BOLT&WASHER | |
| 32 | 26606-52721 | WASHER | |
| 33 | 26676-72061 | BRACKET | |
| 34 | 01183-08016 | BOLT&WASHER | |
| 35 | 26676-72071 | PLATE | |
| 36 | 01183-08016 | BOLT&WASHER | |
| 37 | 01033-06016 | SCREW | |
| 38 | 02000-00008 | WASHER | |
| 39 | 26566-70271 | DUCT | |
| 40 | 01183-08016 | BOLT&WASHER | |
| 41 | 26566-75231 | MAT | |
| 42 | 26566-70261 | DUCT | |
| 43 | 26566-75211 | MAT | |
| 44 | 26566-75221 | MAT | |
| 45 | 26327-82071 | MOUNT, RUBBER | |
| 46 | 21471-22311 | WASHER | |
| 47 | 01100-08040 | BOLT | |
| 48 | 01183-08016 | BOLT&WASHER | |
| 49 | 02000-00008 | WASHER | |
| 50 | 26676-72291 | SPONGE | |
| 51 | 25369-47031 | GRILLE | |
| 52 | 26756-71211 | BRACKET | |
| 53 | 01183-10025 | BOLT&WASHER | |
| 54 | 26602-42071 | CLIP | |
| 55 | 01183-10020 | BOLT&WASHER | |
| 56 | 01401-00010 | NUT |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
