Каталог запасных частей к технике: Hitachi LX-110-7. Valve mechanism

Тип техники Не выбрано Легковые автомобили Грузовые автомобили и прицепы Автобусы Сельхозтехника Спецтехника Двигатели Мототехника

Марка Не выбрано Ammann BOMAG CARMIX CASE IH Changlin ChengGong Dimex Doosan DYNAPAC Foton HAMM Hidromek Hitachi Hyundai JCB JLG John Deere Komatsu LIEBHERR LiuGong Lonking (LongGong) Luneng MANITOU Mitsuber New Holland PENGPU RM-Terex SANY SDLG SEM Shantui Shehwa HBXG Soosan TIGARBO VOGELE Volvo WAY WIRTGEN XCMG XGMA Xiamen YTO Yuchai Zoomlion Автокран АЗСМ Алтайлесмаш Амкодор АОМЗ Атек АТЗ Балканкар Рекорд БелАЗ Беловеж Борекс Брянский Арсенал Булат ВЭКС ГАЗ Геомаш Гидромаш Донекс Дормаш Дормашина Дорэлектромаш ДЭЗ ЕлАЗ ЗЗГТ Ижнефтемаш Канаш-электрокар КЗКТ ККЗ Клевер Клинцовский автокрановый завод КМЗ КМЗ 1 Мая Ковровец Коммаш Кранэкс КЭЗ КЭМЗ ЛЗА МАЗ МЗИК МЗКМ МЗКТ Михневский РМЗ МоАЗ Мозырский МЗ МТЗ ОЗП Онежец ПАО "ТЗА" ППС Детва Промтрактор ПТЗ Раскат СпецАгрегат ТВЭКС ТТМ УВЗ Угличмаш УЗТМ ХТЗ ЧЗКМ ЧСДМ ЧТЗ ЭКСКО ЭКСМАШ ЮрМаш

Модель Не выбрано EX-100-2 (2000) EX-100-3 (2008) EX-100WD (2008) EX-120 (2008) EX-120-2 (2008) EX-160WD (2008) EX-200 (2008) EX-200-2 (2008) EX-200-3 EX-220 (2008) EX-220-2 (2008) EX-270 (2008) EX-300 (2008) EX-300-2 (2000) EX-400 Type A (2006) EX-400 Type B (2006) EX-60 (2003) EX-60-2 (2000) EX-60-3 (2008) EX-70 (2017) LX-110-7 (2008) LX-130-7 (2008) LX-150-2 (2008) LX-160-7 (2008) LX190-7/LX230-7 (2008) Zaxis 190-3 ZAXIS 200-5A (2018) ZAXIS 200LC-5A (2018) ZAXIS 210H-5A (2018) ZAXIS 210K-5A (2018) ZAXIS 210LCH-5A (2018) ZAXIS 210LCK-5A (2018) ZAXIS 330-5G (2017) ZAXIS 350H-5G (2017) ZAXIS 48U-5A (2020) ZAXIS 850-3 ZAXIS 870H-3 ZX-110 (2008) ZX-160W (2008) ZX-200 (2008) ZX-230 (2008) ZX-25 (2008) ZX-270 (2008) ZX-330 (2010) ZX-330-3 (Part № PIHH-I-3) (2008) ZX-330-3 (Part № PIHH-I-5) (2013) ZX-330-3G (2008) ZX-400R-3 (2010) ZX-450 (2006) ZX-600 (2007) Компоненты EX-100-2 (2000) Компоненты EX-100WD (2008) Компоненты EX-120 (2008) Компоненты EX-120-2 (2008) Компоненты EX-160WD (2008) Компоненты EX-200 (2008) Компоненты EX-200-2 (2008) Компоненты EX-200-3(LC, H) Компоненты EX-220 (2008) Компоненты EX-220-2 (2008) Компоненты EX-270 (2008) Компоненты EX-300 (2008) Компоненты EX-300-2 (2000) Компоненты EX-400 Type A (2006) Компоненты EX-400 Type B (2006) Компоненты EX-60 (2003) Компоненты EX-60-2 (2000) Компоненты EX-60-3 (2008) Компоненты ZAXIS 450, 470, 500, 520 (2010) Компоненты ZX-110 (2008) Компоненты ZX-120 (130) (2008) Компоненты ZX-160W (2008) Компоненты ZX-200 (2008) Компоненты ZX-230 (2008) Компоненты ZX-270 (2008) Компоненты ZX-330 (2008) Компоненты ZX-450 (2006)

Схема > Не выбрано Engine mount Generator(GE061-648)(OP) Engine Control Radiator(-2100) Radiator(2101-) Dust proof radiator(DPR-648)(-2100)(OP) Dust proof radiator(DPR-648)(2101-)(OP) Fuel system(-2100) Fuel system(2101-) Air intake & exhaust parts Cylinder block Chamber cover&breather Crankshaft piston&flywheel Gear case Flywheel housing Oil pan Cylinder head Valve mechanism Air intake&exhasut system Muffler Oil pipe Oil pump Oil filter Fan Water pump Thermostat Oil cooler Injection piping Fuel filter Sedimenter Nozzle & nozzle holder Injection pump mount Starter & generator mount Electrical parts & hanger Electrical parts(wire harness) Wiring(front frame) Wiring(cockpit)(1/2)(-2100) Wiring(cockpit)(1/2)(2101-) Wiring(cockpit)(2/2) Wiring(rear frame)(-2100) Wiring(rear frame)(2101-) Battery cable Battery Instrument panel Cluster meter Electrical parts(lamp) Electrical parts(relay&motor)(-2100) Electrical parts(relay&motor)(2101-) Electrical parts(horn&buzzer) Electrical parts(switch) Car stereo(CRS-648)(OP) Revolving lamp(RLY001-648)(OP) Revolving lamp(RLY002-648)(OP) Revolving lamp(RLYS01-648)(OP) Revolving lamp(RLYS02-648)(OP) Automatic transmission(ATM-648)(OP) Cluster meter(ATM-648)(OP) Heater(HR400A-648)(OP) Heater(piping)(HR400A-648)(OP) Heater(electrical)(HR400A-648)(OP) Heater unit(HR40QA-648)(OP) Tachograph(TC0004-648)(OP) Drive unit mount Drive unit(1/3) Drive unit(2/3) Drive unit(3/3) Transmission control valve(1/2) Transmission control valve(2/2) Clutch(forvard&reverse) Clutch(1st&2nd) Clutch(3rd&4th) Torque converter(1/2) Torque converter(2/2) Torque converter wheel Charging pump Drive axle - front(1/3) Drive axle - front(2/3) Drive axle - front(3/3) Drive axle - rear(1/3) Drive axle - rear(2/3) Drive axle - rear(3/3) Planet carrier Wheel Tire chain(TC003-648)(OP) Propeller shaft Brake pedal Brake line(brake valve) Brake valve Brake line(split cylinder-front axle) Brake line(split cylinder-rear axle) Split cylinder Parking brake(-1190) Parking brake(1191-) Stop valve(1191-) Steering wheel unit Steering valve(-2100) Priority valve(-2100) Steering cylinder Front frame Rear frame Balance weight Cockpit Seat mount(-1355) Seat mount(1356-) Seat(1356-) Cockpit mount Rops cab Rops cab(cover&mat) Rops cab(door,RH)(1/2) Rops cab(door,RH)(2/2) Rops cab(door,LH)(1/2) Rops cab(door,LH)(2/2) Rops cab(lamp&radio) Rops cab(wiper) Rops cab(electrical) Rops cab(mount) Steel cab(SCB001-648)(OP) Cab(cover&mat)(SCB001-648) Cab(door,RH)(1/2)(SCB001-648)(OP) Cab(door,RH)(2/2)(SCB001-648)(OP) Cab(door,LH)(1/2)(SCB001-648)(OP) Cab(door,LH)(2/2)(SCB001-648)(OP) Cab(lamp&radio)(SCB001-648)(OP) Cab(wiper)(SCB001-648)(OP) Cab(electrical)(SCB001-648)(OP) Cab(mount)(SCB001-648)(OP) Low cab(LSB150-648)(OP) Cab(cover&mat)(LSB150-648)(OP) Cab(door,RH)(1/2)(LSB150-648)(OP) Cab(door,RH)(2/2)(LSB150-648)(OP) Cab(door,LH)(1/2)(LSB150-648)(OP) Cab(door,LH)(2/2)(LSB150-648)(OP) Cab(lamp&radio)(LSB150-648)(OP) Cab(wiper)(LSB150-648)(OP) Cab(electrical)(LCB150-648)(OP) Cab(mount)(LSB150-648)(OP) Hood&grille(-2100) Hood&grille(2101-) Side panel Lamp bracket&front fender Step&rear fender Battery box Sound absorbing material Air-con less kit(dashboard&mat)(ACLS3-648)(OP) Air conditioner less kit(cover)(ACLS3-648)(OP) Rops cab less kit(ROCLS1-648)(OP) Full rear fender(FRF-648)(OP) Under mirror(UMR001-648) Valve control(1/2) Valve control(2/2) Control valve Control valve(bucket section)(-1324) Control valve(boom section)(-1324) Piping kit with 3 spool valve(LEVER)(AP3-648)(OP) Piping kit with 3 spool valve(PIPING)(AP3-648)(OP) Control valve(AP3-648)(-1344)(OP) Control valve(AP3-648)(1345-)(OP) Piping kit with 4 spool valve(PIPING)(AP4002-648)(OP) Piping kit with 4 spool valve(LEVER)(AP4002-648)(OP) Control valve(AP4002-648)(-2100)(OP) Control valve(AP4002-648)(2101-)(OP) Control valve(bucket section)(AP4002-648)(OP) Control valve(boom section)(AP4002-648)(OP) Lever kit(LK2001-648)(OP) Oil tank Hydraulic line(suction) Main pump(-2100) Hydraulic line(boom&bucket) Hydraulic line(steering) Cushion valve Hydraulic line(transmission) Boom High lift arm(HLA-648)(OP) Boom kickout Bucket Bucket(1type)(B1H150-648)(OP) Bucket(3type)(B3H150-648)(OP) Bucket(double edge)(DBH160-648)(OP) Bucket(double edge)(ODB160-648)(OP) Boom cylinder Bucket cylinder One touch coupler(OTC-648)(OP) Coupler cylinder(OTC-648)(OP) Bucket leveler Logger(TL047-648) Logger(clamp cylinder)(TL047-648) Logger(piping)(TL047-648) Air conditioner(1/2)(-2100) Air conditioner(1/2)(2101-) Air conditioner(2/2)(-2100) Air conditioner(2/2)(2101-) Air conditioner piping(1/2) Air conditioner piping(2/2) Air conditioner (electrical parts) Grease piping Decal(JPN:-1324) 156A decal(JPN:1325-) Service tools

Позиция на иллюстрации	Заводской номер детали		Название детали
1	1-12514-005-0		CAMSHAFT,TIMING
2	1-12522-016-2		GEAR,CAMSHAFT
3	9-0803-0713-0		KEY
4	9-9206-1428-0		BOLT
5	9-09851-850-3		WASHER
6	9-11681-015-0		PLATE,THRUST
7	0-5004-0825-0		BOLT
8	9-12531-030-0		SHAFT,IDLE
9	8-94133-937-3		GEAR,IDLE
10	5-12535-001-1		COLLAR
11	0-1081-1055-0		BOLT
12	9-0915-0510-0		WASHER
13	1-12551-165-0		VALVE,INLET
14	1-12552-111-0		VALVE,EXHAUST
15	1-12561-099-0		SPRING, VALVE
16	8-94114-579-0		SEAT SPRING
17	5-12563-001-0		SEAT SPRING
18	5-12565-006-0		COLLAR
19	5-12571-003-2		TAPEET
20	1-12575-036-0		ROD, PUSH
21	1-12611-249-0		ARM,ROCKER
22	9-12616-042-0		SCREW
23	9-0911-1508-0		NUT
24	1-12621-094-0		SHAFT
25	9-12626-005-0		PLUG
26	5-12628-012-0		BRACKET, ROCKER
27	9-12628-105-0		BRACKET
28	1-09580-335-0		SPRING
29	5-09623-060-0		O RING
30	1-09000-567-0		BOLT
31	9-09602-148-0		BOLT
32	9-09851-430-0		WASHER
33	1-09400-116-0		NUT
34	9-09851-430-0		WASHER
35	9-0918-0019-0		RING,SNAP

Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
