Позиция на иллюстрации
Заводской номер детали
Название детали
1
26552-42551
STARTER SWITCH
2
56550-52231
KEY
3
26562-42141
T/M CONTROL SWITCH
4
01183-06016
BOLT&WASHER
5
26602-43361
TURN SIGNAL SWITCH
6
23232-42072
STOP LAMP SWITCH
7
01402-00010
NUT
8
26752-42161
SWITCH, PRESSURE
9
26812-42981
FUEL SENDER UNIT
10
26602-22202
GASKET
11
01183-06010
BOLT&WASHER
12
26752-42713
BRACKET
13
01183-08016
BOLT&WASHER
14
01400-00008
NUT
15
26752-42703
BRACKET
16
01183-08020
BOLT
