Каталог запасных частей к технике: Hitachi Компоненты ZX-450. MOTOR,OIL (2/2)
4481829
2
10
10
11
11
13
14
15
15
16
17
19
19
20
20
21
21
22
22
23
24
25
25
25
26
27
28
28
33
36
36
36
37
51
52
61
61
62
62
63
63
64
64
65
65
66
66
71
72
73
74
75
76
77
78
79
91
93
94
95
96
97
98
201
202
203
203
204
204
205
205
206
206
207
207
209
221
222
222
223
223
224
224
225
225
400
710
711
712
713
714
715
716
716
717
717
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 4481829 | 4481829 | MOTOR, OIL | |
| KIT | KIT | KIT | |
| 2 | PLATE | PLATE | |
| 10 | 4506407 | O-RING | |
| 11 | ORIFICE | ORIFICE | |
| 13 | 0820203 | SPRING | |
| 14 | 0671002 | PLUG | |
| 15 | 4506418 | O-RING | |
| 16 | 0682803 | PIN | |
| 17 | 0820204 | PLUG | |
| 19 | 0352304 | VALVE, CHECK | |
| 20 | 0352305 | SPRING | |
| 21 | 0352306 | PLUG | |
| 22 | 4506429 | O-RING | |
| 23 | ORIFICE | ORIFICE | |
| 24 | ORIFICE | ORIFICE | |
| 25 | 0436608 | PLUG | |
| 26 | 0809604 | SPRING | |
| 27 | 0251319 | PIN | |
| 28 | PLUG | PLUG | |
| 33 | 0168008 | BOLT SOCKET | |
| 36 | 957366 | O-RING | |
| 37 | PLUG | PLUG | |
| 51 | NAME-PLATE | NAME-PLATE | |
| 52 | SCREW | SCREW | |
| 61 | CAP | CAP | |
| 62 | SCREW | SCREW | |
| 63 | PLUG | PLUG | |
| 64 | O-RING | O-RING | |
| 65 | O-RING | O-RING | |
| 66 | BOLT | BOLT | |
| 71 | SEAT | SEAT | |
| 72 | HOUSING | HOUSING | |
| 73 | POPPET | POPPET | |
| 74 | SEAT | SEAT | |
| 75 | SPRING | SPRING | |
| 76 | PLUG | PLUG | |
| 77 | GUIDE | GUIDE | |
| 78 | SCREW | SCREW | |
| 79 | NUT | NUT | |
| 91 | SPOOL | SPOOL | |
| 93 | FILTER | FILTER | |
| 94 | O-RING | O-RING | |
| 95 | O-RING | O-RING | |
| 96 | RING | RING | |
| 97 | RING | RING | |
| 98 | RING | RING | |
| 201 | PLATE | PLATE | |
| 202 | SPOOL | SPOOL | |
| 203 | 0163601 | SEAT, SPRING | |
| 204 | 0420002 | SPRING | |
| 205 | 0809601 | SEAT SPRING | |
| 206 | 0809602 | CAP ASSY | |
| 207 | 0806602 | VALVE RELIEF | |
| 209 | VALVE | BODY, VALVE | |
| 221 | SPOOL | SPOOL | |
| 222 | VALVE | BODY, VALVE | |
| 223 | SPRING | SPRING | |
| 224 | PLUG | PLUG | |
| 225 | O-RING | O-RING | |
| 400 | 0806801 | PLATE ASSY | |
| 710 | PISTON | PISTON | |
| 711 | O-RING | O-RING | |
| 712 | O-RING | O-RING | |
| 713 | O-RING | O-RING | |
| 714 | O-RING | O-RING | |
| 715 | RING | RING | |
| 716 | RING | RING | |
| 717 | RING | RING |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
