Каталог запасных частей к технике: Hitachi Компоненты ZX-330. MOTOR, OIL (2/2)
4451685
2
16
21
22
23
23
24
24
25
25
26
27
33
51
52
70
70
71
72
73
74
75
76
77
78
79
210
210
211
211
213
214
215
215
217
219
219
220
220
221
222
222
223
223
224
224
225
225
260
260
261
261
262
262
263
263
264
264
265
265
266
266
290
291
293
294
295
296
297
298
321
321
322
322
323
324
325
325
325
326
326
326
327
328
328
400
710
711
712
713
714
715
716
716
717
717
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 4451685 | 4451685 | МОТОR, ОIL | |
| 2 | PLATE | PLATE | |
| 16 | 0682803 | PIN | |
| 21 | PLATE | PLATE | |
| 22 | SPOOL | SPOOL | |
| 23 | 0163601 | SEAT, SPRING | |
| 24 | 0420002 | SPRING | |
| 25 | 0809601 | SEAT SPRING | |
| 26 | 0809604 | SPRING | |
| 27 | 0251319 | PIN | |
| 33 | 0168008 | BOLT SOCKET | |
| 51 | NAME-PLATE | NAME-PLATE | |
| 52 | SCREW | SCREW | |
| 70 | 0802601 | VALVE, RELIEF ASSY | |
| 71 | SEAT | SEAT | |
| 72 | HOUSING | HOUSING | |
| 73 | POPPET | POPPET | |
| 74 | SEAT | SEAT | |
| 75 | SPRING | SPRING | |
| 76 | PLUG | PLUG | |
| 77 | GUIDE | GUIDE | |
| 78 | SCREW | SCREW | |
| 79 | NUT | NUT | |
| 210 | 4506407 | O-RING | |
| 211 | ORIFICE | ORIFICE | |
| 213 | 0820203 | SPRING | |
| 214 | 0671002 | PLUG | |
| 215 | 4506418 | O-RING | |
| 217 | 0820204 | PLUG | |
| 219 | 0352304 | VALVE, CHECK | |
| 220 | 0352305 | SPRING | |
| 221 | SPOOL | SPOOL | |
| 222 | VALVE | BODY, VALVE | |
| 223 | SPRING | SPRING | |
| 224 | PLUG | PLUG | |
| 225 | O-RING | O-RING | |
| 260 | 0820201 | CAP ASSY | |
| 261 | CAP | CAP | |
| 262 | SCREW | SCREW | |
| 263 | PLUG | PLUG | |
| 264 | O-RING | O-RING | |
| 265 | O-RING | O-RING | |
| 266 | BOLT | BOLT | |
| 290 | VALVE | BODY, VALVE | |
| 291 | SPOOL | SPOOL | |
| 293 | FILTER | FILTER | |
| 294 | O-RING | O-RING | |
| 295 | O-RING | O-RING | |
| 296 | RING | RING | |
| 297 | RING | RING | |
| 298 | RING | RING | |
| 321 | 0352306 | PLUG | |
| 322 | 4506429 | O-RING | |
| 323 | ORIFICE | ORIFICE | |
| 324 | ORIFICE | ORIFICE | |
| 325 | 0436608 | PLUG | |
| 326 | 957366 | O-RING | |
| 327 | PLUG | PLUG | |
| 328 | PLUG | PLUG | |
| 400 | 0802602 | PLATE ASSY | |
| 710 | PISTON | PISTON | |
| 711 | O-RING | O-RING | |
| 712 | O-RING | O-RING | |
| 713 | O-RING | O-RING | |
| 714 | O-RING | O-RING | |
| 715 | RING | RING | |
| 716 | RING | RING | |
| 717 | RING | RING |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
