Каталог запасных частей к технике: Hitachi Компоненты ZX-230. CYL., BOOM (R)
4613892
0926601
4355875
4355875
O-RING
0926602
4355875
4355875
RINGSEAL
1
2
3
4
5
6
6
7
7
8
8
9
9
10
10
11
11
12
13
14
14
15
16
16
17
17
17
18
18
19
19
20
21
22
23
25
25
25
25
26
27
28
29
30
31
32
32
33
33
34
34
35
35
36
36
36
37
37
38
38
39
100
200
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 4613892 | 4613892 | CYL. , BOOM, | |
| 0926601 | 0926601 | TUBE, CYL. | |
| 4355875 | 4355875 | BUSHING | |
| O-RING | O-RING | O-RING | |
| 0926602 | 0926602 | ROD, PISTON | |
| 4355875 | 4355875 | BUSHING | |
| RINGSEAL | RINGSEAL | RING, SEAL | |
| 1 | 0926609 | TUBE, CYL ASSY | |
| 2 | 0926610 | ROD, PISTON | |
| 3 | 0926603 | HEAD, CYL. | |
| 4 | 0325904 | BUSHING | |
| 5 | 0237407 | RING, RETAINING | |
| 6 | 4469112 | RING | |
| 7 | 0105301 | PACKING, URING | |
| 8 | 0237419 | RING, BACKUP | |
| 9 | 4428492 | RING, WIPER | |
| 10 | А811120 | O-RING | |
| 11 | 0223704 | RING | |
| 12 | 0409705 | BOLT, SOCKET | |
| 13 | 0829306 | BRG. , CUSHION | |
| 14 | 4469113 | SEAL | |
| 15 | 0737505 | PISTON | |
| 16 | 0223706 | RING | |
| 17 | 0496706 | RING | |
| 18 | 0926604 | RING, SLIDE | |
| 19 | 0223713 | RING | |
| 20 | 0400909 | SHIM | |
| 21 | 0776406 | NUT | |
| 22 | 0309011 | SCREW, SET | |
| 23 | 0111707 | BALL, STEEL | |
| 25 | 0400902 | RING | |
| 26 | 0927501 | PIPE | |
| 27 | 0927502 | PIPE | |
| 28 | 984614 | O-RING | |
| 29 | М341236 | BOLT | |
| 30 | 4506430 | O-RING | |
| 31 | 4486953 | BOLT, SOCKET | |
| 32 | 0926607 | BAND | |
| 33 | 0309017 | BAND | |
| 34 | J021035 | BOLT, SEMS | |
| 35 | А590910 | WASHER, SPRING | |
| 36 | 0236915 | HOLDER | |
| 37 | 0254312 | BOLT | |
| 38 | А590914 | WASHER, SPRING | |
| 39 | J75481 | FITTING, GREASE | |
| 100 | 4624394 | KIT, SEAL | |
| 200 | 0926611 | KIT, BAND |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
