Каталог запасных частей к технике: Hitachi Компоненты ZX-160W. MOTOR, OIL (TRAVEL)
4458181
0898827
0898826
5
8
9
10
11
12
13
17
18
22
23
26
26
26
26
26
26
26
26
27
30
31
41
42
43
44
46
46
46
46
46
46
47
51
61
62
73
74
75
77
78
85
89
90
91
93
94
96
99
103
104
105
115
121
122
123
124
125
126
127
128
129
134
135
136
136
137
139
140
141
149
151
152
160
161
162
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 4458181 | 4458181 | MOTOR, OIL | |
| 0898827 | 0898827 | RING | |
| 0898826 | 0898826 | PISTON | |
| 5 | 0898801 | HOUSING | |
| 8 | 0898802 | PLUG | |
| 9 | 0898803 | RING, RETANING | |
| 10 | 0898804 | RING, SEAL | |
| 11 | 0898805 | RING, BACKUP | |
| 12 | 0898806 | O-RING | |
| 13 | 0898802 | PLUG | |
| 17 | 0898807 | PIN | |
| 18 | 0898808 | NUT | |
| 22 | 0898809 | SHAFT, DRIVE | |
| 23 | 0898810 | SHIM | |
| 26 | 0898815 | RING, BACKUP | |
| 26 | 0898818 | RING, BACKUP | |
| 26 | 0898817 | RING:BACKUP | |
| 26 | 0898816 | RING, BACKUP | |
| 26 | 0898814 | RING, BACKUP | |
| 26 | 0898813 | RING, BACKUP | |
| 26 | 0898812 | RING, BACKUP | |
| 26 | 0898811 | RING, BACKUP | |
| 27 | 0898819 | RING, RETAINING | |
| 30 | 0898820 | BRG., ROL | |
| 31 | 0898821 | BRG., ROL | |
| 41 | 0898822 | CYLINDER | |
| 42 | 0898823 | PLATE | |
| 43 | 0898824 | PIN, CENTER | |
| 44 | 0898825 | PISTON ASS'Y | |
| 46 | 0898828 | SHIM | |
| 46 | 0898829 | SHIM | |
| 46 | 0898830 | SHIM | |
| 46 | 0898831 | SHIM | |
| 46 | 0898832 | SHIM | |
| 46 | 0898833 | SHIM | |
| 47 | 0898834 | SPRING | |
| 51 | 4614460 | VALVE, BRAKE | |
| 61 | 0898835 | PLATE | |
| 62 | 0898836 | SCREW | |
| 73 | 0898837 | PLATE | |
| 74 | 0898838 | PISTON | |
| 75 | 0898839 | TRUNNION | |
| 77 | 0898840 | PISTON | |
| 78 | 0898841 | PIN | |
| 85 | 0898842 | BOLT, SOCKET | |
| 89 | 0898843 | O-RING | |
| 90 | 0898844 | O-RING | |
| 91 | 0898845 | O-RING | |
| 93 | 0898846 | BOLT, SOCKET | |
| 94 | 0898847 | RING | |
| 96 | 0898848 | PIN | |
| 99 | 0898849 | PLUG | |
| 103 | 0898850 | O-RING | |
| 104 | 0838619 | PLUG | |
| 105 | 0898851 | PIN | |
| 115 | 0898852 | VALVE, RELIEF | |
| 121 | 0898853 | HOUSING | |
| 122 | 0898854 | BUSHING | |
| 123 | 0898855 | PISTON | |
| 124 | 0898856 | BUSHING | |
| 125 | 0898857 | COLLAR | |
| 126 | 0898858 | COLLAR | |
| 127 | 0898859 | SPRING | |
| 128 | 0898860 | SPRING | |
| 129 | 0898861 | SPRING | |
| 134 | 0898862 | O-RING | |
| 135 | 0898863 | BOLT, SOCKET | |
| 136 | 0838619 | PLUG | |
| 137 | 0898864 | RING, RETAINING | |
| 139 | 0898865 | PIN | |
| 140 | 0898866 | PIN | |
| 141 | 0838604 | NUT | |
| 149 | 0898867 | RING, RETAINING | |
| 151 | 0898868 | COVER | |
| 152 | 0898869 | SCREW | |
| 160 | 0898870 | BOLT, SOCKET | |
| 161 | 0898871 | O-RING | |
| 162 | 0838619 | PLUG |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
