Каталог запасных частей к технике: Hitachi Компоненты ZX-120 (130). CYL , POSITIONING (WITE HOLDING VALVE)
0904005
TUBE
4352399
4352399
4610572
ROD
4352399
4352399
1
2
3
4
5
6
6
7
7
8
8
9
9
10
10
11
11
12
13
14
14
15
15
15
16
16
17
17
18
19
20
21
23
23
23
23
24
25
25
26
27
28
29
30
31
32
32
33
34
35
36
100
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 0904005 | 0904005 | KIT, BAND | |
| TUBE | TUBE | TUBE | |
| 4352399 | 4352399 | BUSHING, PIN | |
| 4610572 | 4610572 | CYL. | |
| ROD | ROD | ROD | |
| 4352399 | 4352399 | BUSHING, PIN | |
| 1 | 0904001 | TUBE, CYL | |
| 2 | 0904002 | ROD, PISTON | |
| 3 | 0880603 | HEAD, CYL | |
| 4 | 0309204 | BUSHING | |
| 5 | 0236905 | RING, RETAINING | |
| 6 | 0789106 | RING | |
| 7 | 0667404 | PACKING, U-RING | |
| 8 | 0667405 | RING, BACK-UP | |
| 9 | 0667406 | RING, WIPER | |
| 10 | А811135 | O-RING | |
| 11 | 0679904 | RING, BACK-UP | |
| 12 | 0219305 | BOLT, SOCKET | |
| 13 | 0880604 | PISTON | |
| 14 | 0224106 | RING, SEAL ASS'Y | |
| 15 | 0880605 | RING, BACK-UP | |
| 16 | 0880606 | RING, SLIDE | |
| 17 | 0224108 | RING, SLIDE | |
| 18 | 0836111 | SHIM | |
| 19 | 0880607 | NUT | |
| 20 | 0352715 | SCREW, SET | |
| 21 | 0104404 | BALL | |
| 23 | 4067902 | SEAL, DUST | |
| 24 | 0904003 | PIPE | |
| 25 | 0309020 | BOLT, SOCKET | |
| 26 | 984614 | O-RING | |
| 27 | 4610575 | PIPE | |
| 28 | 0904006 | BAND | |
| 29 | 0373419 | BAND | |
| 30 | 0408815 | BOLT | |
| 31 | 0325913 | WASHER | |
| 32 | 0236915 | HOLDER | |
| 33 | 0254312 | BOLT | |
| 34 | А590914 | WASHER, SPRING | |
| 35 | 4611490 | VALVE, HOLDING | |
| 36 | 0148804 | BOLT, SOCKET | |
| 100 | 4608857 | KIT, SEAL |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
