Каталог запасных частей к технике: Hitachi Компоненты ZX-110. VALVE, PILOT (TRAVEL & BLADE)
4051262
2044332
4437433
4437433
4437433
4437433
3087264
3087264
4425290
4425290
4425290
4425290
9184276
4357586
4425305
3087987
4122395
4122395
4205318
4205317
4205317
4425305
3087987
4051262
4205318
3072517
9195307
8063718
CASING
SPOOL
3065877
4335047
984338
4447050
1
2
3
4
5
6
8
10
11
13
20
20
21
21
22
22
24
24
32
33
33
35
36
39
39
40
40
41
41
42
42
48
49
101
201
202
202
210
210
210
211
211
211
212
212
212
214
214
215
215
217
217
271
271
301
301
311
311
313
313
324
324
335
335
412
412
413
420
423
471
471
472
472
501
601
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 4051262 | 4051262 | PIN, SPR1NG | |
| 2044332 | 2044332 | HOLDER | |
| 4437433 | 4437433 | BUSHING | |
| 3087264 | 3087264 | CAM | |
| 4425290 | 4425290 | SCREW, ADJUSTING | |
| 9184276 | 9184276 | VALVE, PILOT | |
| 4357586 | 4357586 | VALVE, PI LOT | |
| 4425305 | 4425305 | PIN | |
| 3087987 | 3087987 | BRACKET | |
| 4122395 | 4122395 | NUT | |
| 4205318 | 4205318 | PIN, SPRING | |
| 4205317 | 4205317 | PIN, SPRING | |
| 4205317 | 4205317 | PIN, SPRING | |
| 4425305 | 4425305 | PIN | |
| 3087987 | 3087987 | BRACKET | |
| 4051262 | 4051262 | PIN, SPR1NG | |
| 4205318 | 4205318 | PIN, SPRING | |
| 3072517 | 3072517 | PUSHER | |
| 9195307 | 9195307 | VALVE, PILOT | |
| 8063718 | 8063718 | CASING ASS'Y | |
| CASING | CASING | CASING | |
| SPOOL | SPOOL | SPOOL | |
| 3065877 | 3065877 | BUSHING | |
| 4335047 | 4335047 | SEAL, OIL | |
| 984338 | 984338 | O-RING | |
| 4447050 | 4447050 | SEAL, OIL | |
| 1 | 4319299 | SPACER | |
| 2 | 4203411 | SHIM | |
| 3 | 4368629 | SPRING, COMPRES. | |
| 4 | 4364970 | GUIDE, SPRING | |
| 5 | 4368630 | SPRING, COMPRES. | |
| 6 | 9151724 | PUSHER, ASSY | |
| 8 | 9184275 | HOLDER | |
| 10 | J781030 | BOLT, SOCKET | |
| 11 | А590910 | WASHER, SPRING | |
| 13 | 9199146 | CAM ASS'Y | |
| 20 | 4027427 | PIN,SPRING | |
| 21 | 4213419 | PIN, SPRING | |
| 22 | 4185600 | O-RING | |
| 24 | А590906 | WASHER, SPRING | |
| 32 | 8077903 | COVER | |
| 33 | J020614 | BOLT, SEMS | |
| 35 | 4208977 | PLUG | |
| 36 | 964255 | O-RING | |
| 39 | 4437432 | SEAT, RUBBER | |
| 40 | 4428902 | DAMPER | |
| 41 | J780612 | BOLT, SOCKET | |
| 42 | 4447067 | O-RING | |
| 48 | 9207567 | PIN ASS'Y | |
| 49 | 9207568 | PIN ASS'Y | |
| 101 | CASING | CASING | |
| 201 | 0630701 | COVER | |
| 202 | 0630702 | PLUG | |
| 210 | 0628908 | SEAL | |
| 211 | 0630703 | SCRAPER | |
| 212 | 4506420 | O-RING | |
| 214 | 0681301 | ROD, PUSH | |
| 215 | 0428906 | WASHER | |
| 217 | 0428907 | WASHER | |
| 271 | 0630705 | BOLT, SOCKET | |
| 301 | SPOOL | SPOOL | |
| 311 | 0630706 | SEAT, SPRING | |
| 313 | 0428910 | WASHER, SPRING | |
| 324 | 0630707 | SPRING | |
| 335 | 0681302 | SPRING | |
| 412 | 0630709 | BUSHING | |
| 413 | 0630710 | SHAFT, CAM | |
| 420 | 0630711 | CAM | |
| 423 | 0179001 | SCREW | |
| 471 | 0630712 | SCREW, SET | |
| 472 | 0630713 | NUT, LOCK | |
| 501 | 0630714 | BELLOWS | |
| 601 | 4345769 | KIT, SEAL |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
