Каталог запасных частей к технике: Hitachi Компоненты EX-200. VALVE, CONTROL (2/4)
4257233
4257233
4257232
4257232
O-RING
O-RING
RING
RING
O-RING
4257234
4257232
4257232
O-RING
O-RING
RING
O-RING
0111715
0111715
4237926
4257232
4257232
4237925
4237927
4224900
23
23
23
24
24
24
24
24
25
25
26
28
28
32
33
33
34
38
39
40
41
42
42
43
44
44
45
46
49
50
51
52
54
61
74
79
79
82
83
84
84
86
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 4257233 | 4257233 | KIT, SEAL | |
| 4257232 | 4257232 | O-RING | |
| 4257232 | 4257232 | O-RING | |
| O-RING | O-RING | O-RING | |
| RING | RING | RING | |
| O-RING | O-RING | O-RING | |
| 4257234 | 4257234 | КIТ, SЕАL | |
| 4257232 | 4257232 | O-RING | |
| O-RING | O-RING | O-RING | |
| RING | RING | RING | |
| O-RING | O-RING | O-RING | |
| 0111715 | 0111715 | O-RING | |
| 0111715 | 0111715 | O-RING | |
| 4237926 | 4237926 | SLEEVE | |
| 4257232 | 4257232 | O-RING | |
| 4250558 | 4250558 | SLEEVE | |
| 4237925 | 4237925 | POPPET | |
| 4250559 | 4250559 | POPPET | |
| 4237927 | 4237927 | SPRING | |
| 4224900 | 4224900 | VALVE, CONTROL | |
| 23 | 0224411 | PLUG | |
| 24 | 0111715 | O-RING | |
| 25 | 0111711 | POPPET | |
| 26 | 0224410 | SPRING | |
| 28 | 4228353 | VALVE, RELIEF | |
| 32 | 0309709 | VАLVЕ, RЕLIЕF | |
| 33 | 0309710 | PLUG ASSY | |
| 34 | 0309711 | РLUG АSSY | |
| 38 | 0309713 | PLUG | |
| 39 | 0309714 | POPPET | |
| 40 | 0309715 | SPRING | |
| 41 | 0309716 | PLUG | |
| 42 | 0309717 | PLUG | |
| 43 | 0125107 | POPPET | |
| 44 | 0125108 | SPRING | |
| 45 | 0309718 | POPPET | |
| 46 | 0309719 | SPRING | |
| 49 | 0309721 | SLEEVE | |
| 50 | 0309733 | PLATE | |
| 51 | 0224423 | BOLT | |
| 52 | А590910 | WASHER, SPRING | |
| 54 | 0224422 | O-RING | |
| 61 | 4506424 | O-RING | |
| 74 | 0309728 | SPRING | |
| 79 | 4228354 | VALVE, RELIEF | |
| 82 | 4239965 | VALVE, RELIEF | |
| 83 | 4242176 | VАLVЕ, RЕLIЕF | |
| 84 | 4250560 | VALVE, CHECK | |
| 84 | 4239608 | VALVE, CHECK | |
| 86 | 0125107 | POPPET |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
