Каталог запасных частей к технике: Hitachi Компоненты EX-160WD. FINAL DRIVE
0362603
0362604
0362605
4240273
0362612
0362519
1
2
5
6
7
8
8
10
10
11
11
12
13
14
15
16
17
18
19
20
20
20
20
20
20
20
21
21
22
24
25
26
27
28
29
30
31
32
33
34
34
34
36
37
38
38
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 0362603 | 0362603 | BOLT | |
| 0362604 | 0362604 | NUT | |
| 0362605 | 0362605 | PIN, SPLIT | |
| 4240273 | 4240273 | FINAL DRIVE | |
| 0362612 | 0362612 | BOLT, PINION | |
| 0362519 | 0362519 | WASHER, SPRING | |
| 1 | 0362601 | CARRIER ASSY | |
| 2 | 0266602 | BOLT | |
| 5 | 0266605 | PLATE | |
| 6 | 0266606 | PLATE, LOCK | |
| 7 | 0362602 | BOLT | |
| 8 | 0266607 | RETAINER | |
| 10 | 0362606 | BRG, DIFF | |
| 11 | 0362607 | CAGE ASSY | |
| 12 | 0266613 | BOLT | |
| 13 | 0266614 | NUT | |
| 14 | 0266615 | ADJ.NUT, RH | |
| 15 | 0266616 | ADJ.NUT, LH | |
| 16 | 0362609 | PINION | |
| 17 | 0362610 | GEAR | |
| 18 | 0266619 | SPIDER | |
| 19 | 0362611 | WASHER, THRUST | |
| 20 | 0266627 | WASHER, 3.4 | |
| 20 | 0266624 | WASHER, 3.1 | |
| 20 | 0266626 | WASHER, 3.3 | |
| 20 | 0266623 | WASHER, 3.0 | |
| 20 | 0266625 | WASHER, 3.2 | |
| 20 | 0266621 | WASHER, 2.8 | |
| 20 | 0266622 | WASHER, 2.9 | |
| 21 | 0266628 | GEAR | |
| 22 | 0266629 | BOLT | |
| 24 | 0268401 | WASHER | |
| 25 | 0266503 | NUT, LOCK | |
| 26 | 0266631 | FLANGE ASSY | |
| 27 | 0266632 | BRG. | |
| 28 | 0266633 | BRG. | |
| 29 | 0266634 | SPACER | |
| 30 | 0266635 | BRG. | |
| 31 | 0266636 | RING, RETAINING | |
| 32 | 0266637 | CAGE | |
| 33 | 0266638 | SEAL, OIL | |
| 34 | 0266639 | SHIM | |
| 34 | 0266640 | SHIM | |
| 34 | 0266641 | SHIM | |
| 36 | 0362613 | BOLT | |
| 37 | 0362614 | BOLT | |
| 38 | 0362507 | WASHER, SPRING |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
