Каталог запасных частей к технике: Hitachi Компоненты EX-100WD. VALVE, PILOT (L)
7024082
4240151
3037552
A810025
4191490
3047989
9100155
4240151
3037551
A810025
4191490
3047989
SPOOL
SPOOL
CASING
7024721
3
3
5
6
9
9
10
11
14
15
18
19
20
21
24
24
25
26
26
27
28
29
31
31
32
33
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 7024082 | 7024082 | CASING ASSY | |
| 4240151 | 4240151 | SEAL, OIL | |
| 3037552 | 3037552 | PUSHER | |
| A810025 | A810025 | O-RING | |
| 4191490 | 4191490 | SEAL, DUST | |
| 3047989 | 3047989 | BUSHING | |
| 9100155 | 9100155 | VALVE, PILOT | |
| 4240151 | 4240151 | SEAL, OIL | |
| 3037551 | 3037551 | PUSHER | |
| A810025 | A810025 | O-RING | |
| 4191490 | 4191490 | SEAL, DUST | |
| 3047989 | 3047989 | BUSHING | |
| SPOOL | SPOOL | SPOOL | |
| CASING | CASING | CASING | |
| 7024721 | 7024721 | CASING ASSY | |
| 3 | 4173208 | SHIM | |
| 5 | 4201915 | SPRING, COMPRES. | |
| 6 | 4166686 | SPRING, COMPRES | |
| 9 | 4177777 | SPACER | |
| 10 | 4179257 | GUIDE, SPRING | |
| 11 | 4177896 | GUIDE, SPRING | |
| 14 | 4210793 | SPRING, COMPRES. | |
| 15 | 4210794 | SPRING, COMPRES. | |
| 18 | 9089809 | PUSHER ASSY | |
| 19 | 9089808 | PUSHER ASSY | |
| 20 | 4184930 | PLATE | |
| 21 | 4259780 | BOLT, SOCKET | |
| 24 | 4184929 | PISTON | |
| 25 | 984338 | O-RING | |
| 26 | 4269584 | PLATE | |
| 26 | 4280624 | PLATE | |
| 27 | A810060 | O-RING | |
| 28 | M341225 | BOLT, SOCKET | |
| 29 | 4269638 | ORIFICE | |
| 31 | 4183035 | JOINT, UNIVERSAL | |
| 31 | 4285209 | JOINT, UNIVERSAL | |
| 32 | 4184931 | CAM | |
| 33 | 4182067 | JOINT, SCREW |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
