Каталог запасных частей к технике: Hitachi Компоненты EX-100WD. MOTOR, OIL (2/2)
4199024
COVER
COVER
PLUG
PLUG
PLUG
PISTON
PISTON
2
12
14
17
20
21
25
27
32
33
34
35
41
45
45
46
48
48
49
49
50
50
51
51
52
53
53
53
54
55
56
57
58
59
59
60
61
62
63
64
66
67
68
70
71
72
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 4199024 | 4199024 | MOTOR, OIL | |
| COVER | COVER | COVER | |
| PLUG | PLUG | PLUG | |
| PISTON | PISTON | PISTON | |
| 2 | 0311302 | COVER ASSY | |
| 12 | 0224912 | BRG., NEEDLE | |
| 14 | 0311310 | COLLAR | |
| 17 | 0311313 | PIN | |
| 20 | 0311314 | PIN | |
| 21 | 0311315 | PLUG | |
| 25 | 0311318 | BOLT, SOCKET | |
| 27 | 0311319 | PLUG | |
| 32 | 957366 | O-RING | |
| 33 | NAME-PLATE | NAME-PLATE | |
| 34 | SCREW | SCREW | |
| 35 | PLUG | PLUG | |
| 41 | 0311325 | SPRING | |
| 45 | PLUG | PLUG | |
| 46 | 0311326 | FILTER | |
| 48 | 94-2011 | PLUG | |
| 49 | 0311327 | BALL, STEEL | |
| 50 | 0311328 | SPRING | |
| 51 | 0311329 | GUIDE, SPRING | |
| 52 | 0311330 | ORIFICE | |
| 53 | 0311331 | WASHER | |
| 54 | 0311332 | HOUSING | |
| 55 | 0311333 | SCREW, SET | |
| 56 | 0311334 | VALUE | |
| 57 | 0311335 | SPRING | |
| 58 | 0311336 | PLUG | |
| 59 | 4509180 | O-RING | |
| 60 | 0111711 | POPPET | |
| 61 | 0224411 | PLUG | |
| 62 | 0111715 | O-RING | |
| 63 | 0311337 | SPRING | |
| 64 | 4206608 | VALVE, RELIEF | |
| 66 | 0311339 | MASHER | |
| 67 | 0159710 | PLUG | |
| 68 | 0111809 | O-RING | |
| 70 | 0311340 | SPRING | |
| 71 | 0311341 | PLUG | |
| 72 | 4140470 | O-RING |
