Каталог запасных частей к технике: Hitachi Компоненты EX-100WD. BOOSTER
4186190
SEAL
O-RING
RETAINER
SEAL
FITTING
BODY
SEAL
STEM
PISTON
PLUG
YOKE
ROD
RETAINER
VALVE
7
7
8
12
13
13
15
16
36
40
40
41
42
49
49
50
54
55
56
57
57
58
59
59
60
60
61
63
63
66
67
67
69
69
70
73
76
82
83
83
84
84
84
85
85
85
95
106
107
108
109
110
111
112
126
127
128
129
131
131
138
178
197
205
400
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 4186190 | 4186190 | BOOSTER | |
| SEAL | SEAL | SEAL | |
| O-RING | O-RING | O-RING | |
| RETAINER | RETAINER | RETAINER | |
| SEAL | SEAL | SEAL | |
| FITTING | FITTING | FITTING | |
| BODY | BODY | BODY | |
| SEAL | SEAL | SEAL | |
| STEM | STEM | STEM, VALVE | |
| PISTON | PISTON | PISTON | |
| PLUG | PLUG | PLUG | |
| YOKE | YOKE | YOKE | |
| ROD | ROD | ROD | |
| RETAINER | RETAINER | RETAINER | |
| VALVE | VALVE | BODY, VALVE | |
| 7 | 0267701 | RETAINER ASSY | |
| 8 | 0288901 | BODY ASSY | |
| 12 | 0267703 | WASHER | |
| 13 | 4049085 | RING, RETAINING | |
| 15 | 0267704 | PLUG | |
| 16 | 0267705 | PROTECTOR | |
| 36 | 0267706 | VALVE ASSY | |
| 40 | 0267707 | RING, RETAINING | |
| 41 | 0267708 | RETAINER | |
| 42 | 0267709 | SPRING | |
| 49 | 0288920 | HYD. PISTON ASSY | |
| 50 | 0288902 | PISTON ASSY | |
| 54 | 0267711 | SPRING | |
| 55 | 0288903 | SEAL, VALVE ASSY | |
| 56 | 0267713 | RING, RETAINING | |
| 57 | 0288904 | PACKING, CUP | |
| 58 | 0267715 | SPRING | |
| 59 | 0288905 | RING, BACK-UP | |
| 60 | 0267729 | PIN, STRAIGHT | |
| 61 | 0288906 | PLATE, PISTON | |
| 63 | 0267718 | WASHER | |
| 66 | 0267719 | NUT | |
| 67 | 0288907 | PACKING, CUP | |
| 69 | 0267721 | O-RING | |
| 70 | 0288908 | SHELL ASSY | |
| 73 | 0288909 | BOLT | |
| 76 | 0288910 | ROD, PUSH | |
| 82 | 0288911 | SPRING | |
| 83 | 0288912 | O-RING | |
| 84 | 0288913 | NUT | |
| 85 | 0288914 | WASHER | |
| 95 | NAME-PLATE | NAME-PLATE | |
| 106 | 0267736 | COVER ASSY | |
| 107 | COVER | COVER | |
| 108 | PLATE | PLATE | |
| 109 | PLATE | PLATE | |
| 110 | HAIR | HAIR, AIR CLEANER | |
| 111 | PIPE | PIPE | |
| 112 | RETAINER | RETAINER | |
| 126 | 0288917 | CONNECTOR ASSY | |
| 127 | BUSHING | BUSHING | |
| 128 | NET | NET, WIRE | |
| 129 | CONNECTOR | CONNECTOR | |
| 131 | 0267738 | O-RING | |
| 138 | 0288918 | RETAINER | |
| 178 | 0267746 | WASHER | |
| 197 | 0288919 | BRACKET | |
| 205 | 0267748 | PIN, STRAIGHT | |
| 400 | 4185291 | KIT, REPAIR |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
