Каталог запасных частей к технике: Hitachi EX-70. ELECTRICAL PARTS-3
1
2
3
3
4
5
6
7
8
9
9
10
11
12
13
14
15
15
15
16
16
16
17
17
17
18
19
20
21
22
22
23
23
24
24
25
25
26
26
27
27
28
29
30
31
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | ТС20483 | HARNESS, ENGINE | |
| 2 | 4190261 | CLIP | |
| 3 | J901020 | BOLT | |
| 3 | J901025 | BOLT | |
| 4 | А590110 | WASHER, PLANE | |
| 5 | А590910 | WASHER, SPRING | |
| 6 | 4190272 | CLIP | |
| 7 | 4190253 | CLIP | |
| 8 | 4190274 | CLIP | |
| 9 | 4055311 | CLIP, BAND | |
| 10 | ТЕ25868 | PLATE | |
| 11 | 0009971881J | GROMET | |
| 12 | 0429920020J | SLEEVE | |
| 13 | ТЕ23986 | RELAY: BATTERY | |
| 14 | ТЕ24439 | GROMMET, BATTERY RELAY | |
| 15 | 4055312 | CLIP, BAND | |
| 16 | J900620 | BOLT | |
| 17 | А590106 | WASHER, PLANE | |
| 18 | J950006 | NUT | |
| 19 | TD22171 | RELAY, STARTER | |
| 20 | ТЕ02661 | SL CH SCREW | |
| 21 | А590105 | WASHER, PLANE | |
| 22 | J950005 | HEX NUT | |
| 22 | М500504 | NUT | |
| 23 | J900620 | BOLT | |
| 24 | А590906 | WASHER, SPRING | |
| 25 | А590106 | WASHER, PLANE | |
| 26 | ТЕ24194 | BRACKET, MAIN FUSE ASSEMBLY | |
| 27 | ТЕ25262 | BUSHING, RUBBER | |
| 28 | ZC00000097 | WORK LAMP | |
| 29 | ТЕ25289 | BEADING | |
| 30 | TD21063 | COVER | |
| 31 | 4190282 | CLIP | |
| 32 | J901030 | BOLT |
