Каталог запасных частей к технике: Hitachi EX-60-2. Oil Cooler Pipings (1)
01
01
02
02
03
03
03
03
04
05
06
06
07
07
08
09
09
11
12
13
15
15
16
16
16
16
16A
16A
17
17
17
17
20
20
21
21
21
22
22
22
22
22A
22A
22A
22A
23
23
23A
24
24
24
24
24
24
72
73
73A
75
75A
78
80
81
82
83
83
84
85
111
111A
112
112A
113
113
114
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 01 | J901430 | BOLT | |
| 02 | A590914 | WASHER, SPRING | |
| 03 | 4286884 | VALVE CONTROL | |
| 03 | 4325469 | VALVE CONTROL | |
| 03 | 4305191 | VALVE CONTROL | |
| 03 | 4325470 | VALVE CONTROL | |
| 04 | 7024331 | BRACKET | |
| 05 | 6011793 | BRACKET | |
| 06 | J011230 | BOLT, SEMS | |
| 07 | 4086891 | WASHER | |
| 08 | 4294186 | HOSERUBBER | |
| 09 | 4504491 | CLAMP, HOSE | |
| 11 | 7025640 | PIPE SUCTION | |
| 12 | A811075 | O-RING | |
| 13 | M341236 | BOLT, SOCKET | |
| 15 | 421738B | HOSE | |
| 16 | 4189619 | ADAPTER, S | |
| 16 | 4189619 | ADAPTER, S | |
| 16A | 4506424 | O-RING | |
| 17 | 4187308 | O-RING | |
| 20 | 4247593 | HOSE | |
| 20 | 4197700 | HOSE | |
| 21 | 4205338 | HOSE | |
| 21 | 4207995 | HOSE | |
| 22 | 4189619 | ADAPTER, S | |
| 22 | 4157562 | ELBOW, S | |
| 22A | 4506424 | O-RING | |
| 23 | 4157562 | ELBOW, S | |
| 23A | 4506424 | O-RING | |
| 24 | 4187308 | O-RING | |
| 72 | 4218061 | HOSE NYLON | |
| 73 | 4200465 | ADAPTER, S | |
| 73A | 957366 | O-RING | |
| 75 | 4154670 | ELBOW, S | |
| 75A | 957366 | O-RING | |
| 78 | 4301704 | PROTECTOR | |
| 80 | 4303988 | CLAMP PIPE | |
| 81 | 4285722 | RUBBER | |
| 82 | 4303989 | PLATE | |
| 83 | J901080 | BOLT | |
| 83 | J901090 | BOLT | |
| 84 | А590910 | WASHER, SPRING | |
| 85 | J222010 | WASHER | |
| 111 | 4218070 | TEE S | |
| 111A | 4506424 | O-RING | |
| 112 | 4189619 | ADAPTER, S | |
| 112A | 4506424 | O-RING | |
| 113 | 4187308 | O-RING | |
| 114 | 4204161 | HOSE |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
