Каталог запасных частей к технике: Hitachi EX-60. COVER (1)
00
01
02
03
04
06
07
09
09A
10
10A
11
11
12
12
13
14
15
16
18
20
22
23
24
25
26
27
29
30
31
33
34
35
38
39
40
44
44A
45
46
47
48
49
50
55
57
57
57
59
59A
63
65
66
67
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 00 | 7017808 | SUPPORT | |
| 01 | 9726998 | SUPPORT | |
| 02 | 9726999 | SUPPORT | |
| 03 | 9727000 | SUPPORT | |
| 04 | 8037584 | SUPPORT | |
| 06 | J901225 | BOLT | |
| 07 | A590112 | WASHER, PLANE | |
| 09 | 7017809 | DOOR | |
| 09A | 7017862 | DOOR LOCK | |
| 10 | 7017811 | DOOR | |
| 10A | 7017924 | DOOR LOCK | |
| 11 | J950012 | NUT | |
| 12 | A590112 | WASHER, PLANE | |
| 13 | 4188492 | STOPPER | |
| 14 | J901225 | BOLT | |
| 15 | A590112 | WASHER, PLANE | |
| 16 | 7018329 | COVER | |
| 18 | J901225 | BOLT | |
| 20 | 7018418 | COVER | |
| 22 | J901225 | BOLT | |
| 23 | A590112 | WASHER, PLANE | |
| 24 | 449490 | WASHER | |
| 25 | 3037409 | COVER | |
| 26 | J901225 | BOLT | |
| 27 | A590112 | WASHER, PLANE | |
| 29 | 7017813 | COVER | |
| 30 | J901225 | BOLT | |
| 31 | A590112 | WASHER, PLANE | |
| 33 | 8037585 | COVER | |
| 34 | J901225 | BOLT | |
| 35 | A590112 | WASHER, PLANE | |
| 38 | 9720341 | STAY | |
| 39 | A590112 | WASHER, PLANE | |
| 40 | 4022699 | PIN, LOCK | |
| 44 | 6008283 | COVER, ENGINE | |
| 44A | 7017862 | DOOR LOCK | |
| 45 | J901230 | BOLT | |
| 46 | A590112 | WASHER, PLANE | |
| 47 | A590912 | WASHER, SPRING | |
| 48 | 4198183 | STOPPER | |
| 49 | J901225 | BOLT | |
| 50 | A590112 | WASHER, PLANE | |
| 55 | 445100 | BUSHING, RUBBER | |
| 57 | 4121128 | TAPE 150X200 | |
| 59 | 6008498 | COVER | |
| 59A | 7017862 | DOOR LOCK | |
| 63 | J031230 | BOLT, SEMS | |
| 65 | M500807 | NUT | |
| 66 | A590918 | WASHER, SPRING | |
| 67 | A590108 | WASHER, PLANE |
