Каталог запасных частей к технике: Hitachi EX-60. CAB (2)
1
13
14
15
16
16
17
17
18
18
19
19
20
20
21
22
23
24
25
26
27
28
28
29
29
30
30
31
31
32
33
34
35
35
36
37
37
38
39
40
41
41
42
42
42
43
43
44
44
44
80
80
81
82
83
83
83
83
84
84
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 4141616 | WEATHER STRIP | |
| 13 | 4217826 | FRAME | |
| 14 | 4147957 | LOCK | |
| 15 | 4147958 | LOCK | |
| 16 | J901016 | BOLT | |
| 17 | A590910 | WASHER, SPRING | |
| 18 | 4141623 | ROLLER | |
| 19 | A590105 | WASHER, PLANE | |
| 20 | 4141748 | SCREW | |
| 21 | 4141620 | PLATE | |
| 22 | 4141621 | rubber | |
| 23 | M470516 | SCREW | |
| 24 | 4217827 | GLASS | |
| 25 | 4141617 | WEATHER STRIP | |
| 26 | 4217828 | BRACKET | |
| 27 | 4217829 | BRACKET | |
| 28 | 4141626 | RUBBER | |
| 29 | 4141741 | SCREW | |
| 30 | A590108 | WASHER, PLANE | |
| 31 | 4148517 | WASHER | |
| 32 | 4141743 | SCREW | |
| 33 | 4217831 | GLASS | |
| 34 | 4217830 | WEATHER STRIP | |
| 35 | 4217832 | WEATHER STRIP | |
| 36 | 4217935 | RUBBER | |
| 37 | 4141880 | BUSHING, RUBBER | |
| 38 | 4217833 | BRACKET | |
| 39 | 4217834 | BRACKET | |
| 40 | 4217835 | BRACKET | |
| 41 | 4233072 | WEATHER STRIP | |
| 41 | 4217836 | WEATHER STRIP | |
| 42 | 4217837 | WEATHER STRIP | |
| 42 | 4233073 | WEATHER STRIP | |
| 43 | 4219493 | SCREW | |
| 44 | 4217838 | SCREW | |
| 80 | 4141693 | STOPPER | |
| 81 | 4141695 | STOPPER | |
| 82 | 4141696 | STOPPER | |
| 83 | 4217936 | SHIM | |
| 84 | 4141743 | SCREW |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
