Каталог запасных частей к технике: Hitachi EX-220. OIL COOLER PIPINGS (2)
01
01
17
17
32
33
33
34
35
36
37
38
40
41
41
41
41
42
42
44
45
46
47
48
49
49
50
50
51
52
54
54
54
55
55
55
56
56
56
56
56
56
57
57
57
57
67
67
67
67
75
76
77
77
77A
77A
78
78
79
79
88
88
88A
88A
89
90
96
96
97
97
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 01 | А590912 | WASHER, SPRING | |
| 17 | А590112 | WASHER, PLANE | |
| 32 | 2022811 | MANIFOLD | |
| 33 | M341060 | BOLT, SOCKET | |
| 34 | М341022 | BOLT, SOCKET | |
| 35 | А811040 | O-RING | |
| 36 | 4188627 | VALVE | |
| 37 | 4188628 | RING | |
| 38 | 991721 | RING, RETAINING | |
| 40 | 4120294 | HOSE, RUBBER | |
| 41 | 4156850 | CLAMP, HOSE | |
| 41 | 4263764 | CLAMP, HOSE | |
| 42 | 4504491 | CLAMP, HOSE | |
| 44 | М341036 | BOLT, SOCKET | |
| 45 | А811045 | O-RING | |
| 46 | 3038718 | PIPE, RETURN | |
| 47 | 9727929 | PIPE, RETURN | |
| 48 | 4080206 | HOSE, RUBBER | |
| 49 | 4505385 | CLAMP, HOSE | |
| 49 | 4282474 | CLAMP, HOSE | |
| 50 | 4159683 | CLAMP, HOSE | |
| 51 | 7018364 | PIPE, RETURN | |
| 52 | 4204745 | VALVE | |
| 54 | 4069801 | COUPLING | |
| 55 | 4053698 | CLAMP | |
| 56 | J901270 | BOLT | |
| 56 | J011270 | BOLT, SEMS | |
| 57 | А590912 | WASHER, SPRING | |
| 67 | 4187308 | O-RING | |
| 75 | 4204160 | HOSE | |
| 76 | 4204162 | HOSE | |
| 77 | 4157562 | ELBOW, S | |
| 77A | 4506424 | O-RING | |
| 78 | 4204882 | PLUG | |
| 79 | J901230 | BOLT | |
| 88 | 4200465 | ADAPTER, S | |
| 88A | 957366 | O-RING | |
| 89 | 4204183 | HOSE, NYLON | |
| 90 | 4204184 | HOSE, NYLON | |
| 96 | 9727918 | PIPE, RETURN | |
| 96 | 9728575 | PIPE, RETURN | |
| 97 | A811045 | O-RING | |
| 97 | A811040 | O-RING |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
