Каталог запасных частей к технике: Hitachi EX-200. COVER (1)
00
01
02
03
04
09
09
10
10
10
10
10
10
10
10
11
11
11
11
11
11
11
11
12
12
12
12
12
12
12
13
13
14
15
16
17
17
20
21
22
22
22
22
22
22
23
23
23
23
24
25
25
26
27
27
28
29
33
33
33A
35
36
37
38
38
39
40
41
42
43
44
85
85
85
86
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 00 | 8035504 | SUPPORT | |
| 01 | 8035522 | SUPPORT | |
| 02 | 8035518 | SUPPORT | |
| 03 | 8035525 | SUPPORT | |
| 04 | 8035526 | SUPPORT | |
| 09 | 449490 | WASHER | |
| 10 | J901230 | BOLT | |
| 11 | А590912 | WASHER, SPRING | |
| 12 | А590112 | WASHER, PLANE | |
| 13 | J950012 | NUT | |
| 14 | 4203941 | PLATE | |
| 15 | 8035517 | СОVЕR | |
| 16 | 7018319 | PLATE | |
| 17 | 8038306 | COVER | |
| 17 | 8040311 | COVER | |
| 20 | 4202172 | BRACKET | |
| 21 | 4147883 | STOPPER | |
| 22 | J901225 | BOLT | |
| 23 | А590112 | WASHER, PLANE | |
| 24 | J901022 | BOLT | |
| 25 | А590910 | WASHER, SPRING | |
| 26 | J217083 | WASHER | |
| 27 | А590120 | WASHER | |
| 28 | А590912 | WASHER, SPRING | |
| 29 | J952010 | NUT | |
| 33 | 6007814 | DOOR | |
| 33 | 6010026 | DOOR | |
| 33A | 7017862 | DOOR LOCK | |
| 35 | J950012 | NUT | |
| 36 | А590912 | WASHER, SPRING | |
| 37 | 4188492 | STOPPER | |
| 38 | J901230 | BOLT | |
| 38 | J021230 | BOLT, SEMS | |
| 39 | А590912 | WASHER, SPRING | |
| 40 | А590112 | WASHER, PLANE | |
| 41 | 3037786 | BRACKET | |
| 42 | J900812 | BOLT | |
| 43 | А590908 | WASHER, SPRING | |
| 44 | А590108 | WASHER, PLANE | |
| 85 | 4073519 | TAPE 150X400 | |
| 86 | 4121128 | TAPE 150X200 |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
