Каталог запасных частей к технике: Hitachi EX-160WD. AIR PIPINGS (1)
7019899
1
4
5
6
7
8
10
10
12
14
15
16
17
19
20
20
22
22
23
24
24
25
25
26
27
28
28
29
30
31
33
34
35
36
37
38
39
40
43
44
44
45
47
48
50
51
53
54
55
56
58
58
58
59
59
59
59
60
61
62
62
63
63
64
64
65
66
67
68
69
72
72
73
74
75
76
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 7019899 | 7019899 | BRACKET | |
| 1 | J031230 | BOLT, SEMS | |
| 4 | 4216546 | DRIYER, AIR | |
| 5 | J901025 | BOLT | |
| 6 | A590110 | WASHER, PLANE | |
| 7 | A590910 | WASHER, SPRING | |
| 8 | J950010 | NUT | |
| 10 | 4207744 | ELBOW, S | |
| 10 | 4154657 | ELBOW, S | |
| 12 | 4154656 | ELBOW, S | |
| 14 | 94-1602 | REDUCER | |
| 15 | 4216547 | TANK, AIR | |
| 16 | 4225005 | BOLT, U | |
| 17 | J950010 | NUT | |
| 19 | 4216548 | VALVE, DRAIN | |
| 20 | 94-2024 | PLUG | |
| 22 | 94-0632 | ELBOW, S | |
| 23 | 94-1602 | REDUCER | |
| 24 | 499820 | ADAPTER | |
| 25 | 984219 | SEAL WASHER 20 | |
| 26 | 4092238 | GOVERNOR | |
| 27 | 94-0661 | TEE, S | |
| 28 | 4154657 | ELBOW, S | |
| 29 | 4215649 | ADAPTERS | |
| 30 | 94-1902 | ADAPTER, S | |
| 31 | 986953 | CHECK VALVE | |
| 33 | 4214336 | ADAPTER | |
| 34 | 94-1702 | ADAPTER, S | |
| 35 | 4216549 | VALVE | |
| 36 | 4215650 | ADAPTER, S | |
| 37 | 4157919 | ELBOW, S | |
| 38 | 986952 | VALVE, SAFETY | |
| 39 | 4206449 | SWITCH, PRES | |
| 40 | 4168339 | UNIT | |
| 43 | 4172139 | VALVE, SOLENOID | |
| 44 | J020620 | BOLT, SEMS | |
| 44 | J460520 | SCREW, SEMS | |
| 45 | 4168366 | SILENCER | |
| 47 | 4151536 | VALVE, SOLENOID | |
| 48 | J010645 | BOLT, SEMS | |
| 50 | 4135434 | VALVE | |
| 51 | J020620 | BOLT, SEMS | |
| 53 | 4225006 | ADAPTER | |
| 54 | 4214338 | ADAPTER | |
| 55 | 4225007 | ADAPTER | |
| 56 | 4214340 | ADAPTER | |
| 58 | 4215648 | ADAPTER, S | |
| 59 | 4154651 | ADAPTER, S | |
| 60 | 94-1901 | ADAPTER, S | |
| 61 | 94-1702 | ADAPTER, S | |
| 62 | 986953 | CHECK VALVE | |
| 63 | 4154657 | ELBOW, S | |
| 64 | 4086377 | SWITCH, PRES. | |
| 65 | 4157919 | ELBOW, S | |
| 66 | 4224412 | ELBOW, S | |
| 67 | 94-0630 | ELBOW, S | |
| 68 | 94-1701 | ADAPTER, S | |
| 69 | 4170939 | VALVE, THROTTLE | |
| 72 | 4224415 | HOSE | |
| 73 | 4224416 | HOSE | |
| 74 | 4216435 | HOSE | |
| 75 | 4224417 | HOSE | |
| 76 | 4224418 | HOSE |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
