Каталог запасных частей к технике: Hitachi EX-120. OIL TANK
00
01
02
03
03
04
04
06
06
06A
06B
07
08
10
10
11
11
12
14
15
15
16
16
17
17A
17B
17C
17D
17E
20
21
23
23
24
27
28
28A
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 00 | 6007798 | TANK OIL | |
| 01 | J901640 | BOLT | |
| 02 | J901680 | BOLT | |
| 03 | A590916 | WASHER, SPRING | |
| 04 | 4114405 | WASHER | |
| 06 | 4156753 | ELEMENT, FILTER ASSY | |
| 06 | 4227353 | ELEMENT, FILTER ASSY | |
| 06A | 4132686 | ELEMENT, FILTER | |
| 06B | A810145 | O-RING | |
| 07 | 4065280 | VALVE | |
| 08 | 4109393 | SPRING | |
| 10 | A590910 | WASHER, SPRING | |
| 11 | J901020 | BOLT | |
| 11 | J011020 | BOLT, SEMS | |
| 12 | A590910 | WASHER, SPRING | |
| 14 | 8033464 | COVER | |
| 15 | M111022 | BOLT | |
| 16 | A810160 | O-RING | |
| 17 | 4178684 | breather, air | |
| 17A | 4222874 | FILTER | |
| 17B | 953612 | O-RING | |
| 17C | M340516 | bolt, socket | |
| 17D | 4222875 | CASE | |
| 17E | 4222876 | PACKING | |
| 20 | 449558 | WASHER, SEAL | |
| 21 | 7017641 | PIPE SUCTION | |
| 23 | 4125320 | FILTER, SUCTION | |
| 23 | 4190987 | FILTER, SUCTION | |
| 24 | 94-2011 | PLUG | |
| 27 | 4202009 | COVER | |
| 28 | 8038196 | GAUGE, LEVEL | |
| 28A | 4100967 | BOLT |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
