Каталог запасных частей к технике: Hitachi EX-120. COVER (1)
00
01
02
03
10
10
10
10
10
10
10
11
11
11
11
11
11
11
13
14
15
18
18A
20
21
24
25
26
28
28
28
28
29
29
29
29
30
31
31
31
31
31
31
32
32
32
32
32
32
34
35
37
37
38
39
58
59
60
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 00 | 8035761 | SUPPORT | |
| 01 | 9725444 | SUPPORT | |
| 02 | 8035763 | SUPPORT | |
| 03 | 7017192 | SUPPORT | |
| 04 | 9725446 | SUPPORT | |
| 10 | J901225 | BOLT | |
| 11 | A590112 | WASHER, PLANE | |
| 13 | 4189739 | PLATE | |
| 14 | J901020 | BOLT | |
| 15 | A590910 | WASHER, SPRING | |
| 18 | 6007860 | DOOR | |
| 18A | 7017862 | DOOR LOCK | |
| 20 | J950012 | NUT | |
| 21 | A590112 | WASHER, PLANE | |
| 24 | 4188492 | STOPPER | |
| 25 | J901225 | BOLT | |
| 26 | A590112 | WASHER, PLANE | |
| 28 | 8036230 | COVER | |
| 28 | 8042306 | COVER | |
| 29 | 3036050 | COVER | |
| 29 | 3042536 | COVER | |
| 30 | 4124915 | BUSHING RUBBER | |
| 31 | J901225 | BOLT | |
| 31 | J901225 | BOLT | |
| 32 | 449490 | WASHER | |
| 32 | 449490 | WASHER | |
| 34 | 4189740 | COVER | |
| 35 | 8035765 | COVER | |
| 37 | J901225 | BOLT | |
| 38 | A590112 | WASHER, PLANE | |
| 39 | 449490 | WASHER | |
| 58 | 4204023 | COVER | |
| 59 | J901225 | BOLT | |
| 60 | 449490 | WASHER |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
