Каталог запасных частей к технике: Hitachi EX-100WD. BLADE PIPINGS (SUPERSTRUCTURE)
00
01
02
03
04
06
07
07A
08
09
09A
10
12
13
13A
14
15
15A
17
17A
20
21
22
22A
24
25
26
27
28
30
30A
31
31A
32
32
34
36
36A
38
38A
39
40
40
42
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 00 | 4199095 | VALVE, SOLENOID | |
| 01 | 4217247 | BRACKET | |
| 02 | J901022 | BOLT | |
| 03 | A590910 | WASHER, SPRING | |
| 04 | M340860 | BOLT, SOCKET | |
| 06 | 4217325 | HOSE, NYLON | |
| 07 | 4200472 | ELBOW, S | |
| 07A | 957366 | O-RING | |
| 08 | 4217324 | HOSE, NYLON | |
| 09 | 4156434 | ELBOW, S | |
| 09A | 957366 | O-RING | |
| 10 | 4154651 | ADAPTER, S | |
| 12 | 4217326 | HOSE, NYLON | |
| 13 | 4208909 | TEE, S | |
| 13A | 4509180 | O-RING | |
| 14 | 4221264 | HOSE, NYLON | |
| 15 | 4200467 | ADAPTER, S | |
| 15A | 957366 | O-RING | |
| 17 | 4154671 | ELBOW | |
| 17A | 4509180 | O-RING | |
| 20 | 4217327 | HOSE, NYLON | |
| 21 | 4217329 | HOSE, NYLON | |
| 22 | 4208913 | ELBOW, S | |
| 22A | 4509180 | O-RING | |
| 24 | 4510173 | FLANGE, SPLIT | |
| 25 | 4510167 | O-RING | |
| 26 | M340825 | BOLT, SOCKET | |
| 27 | 4217331 | HOSE | |
| 28 | 4217332 | HOSE | |
| 30 | 4189602 | ADAPTER, S | |
| 30A | 4506418 | O-RING | |
| 31 | 4200580 | ELBOW, S | |
| 31A | 4506418 | O-RING | |
| 32 | 4138938 | O-RING | |
| 34 | 4209355 | SWITCH | |
| 36 | 4223934 | ADAPTER, S | |
| 36A | 957366 | O-RING | |
| 38 | 4093624 | PLUG | |
| 38A | 957366 | O-RING | |
| 39 | 4239766 | HOSE, NYLON | |
| 40 | 4133527 | PROTECTOR | |
| 42 | 4241193 | NAME-PLATE |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
