4338854
1
2
2
4
4
4
04A
04A
04A
7
9
10
11
39
40
41
41
42
44
44A
Позиция на иллюстрации
Заводской номер детали
Название детали
4338854
4338854
VALVE, FC
1
J010816
BOLT, SEMS
2
4254563
SWITCH, PRESSURE
4
4200466
ADAPTER, S
04A
4509180
O-RING
7
4260474
HOSE, NYLON
9
4269942
HOSE, NYLON
10
4285679
HOSE, NYLON
11
4285680
HOSE, NYLON
39
4193816
CLIP
40
J011025
BOLT, SEMS
41
4055312
CLIP, BAND
42
4217147
BUSHING, RUBBER
44
4326876
SENSOR, PRES.
44A
4150302
O-RING
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
