00
01
04
05
06
07
08
11
11
12
13
16A
16A
16B
16B
17A
17A
17B
17B
19
78
78A
79
Позиция на иллюстрации
Заводской номер детали
Название детали
00
9737118
SUPPORT
01
J021225
BOLT, SEMS
04
8047349
PIPE
05
8047348
PIPE
06
4510167
O-RING
07
4510173
FLANGE, SPLIT
08
М340825
BOLT, SOCKET
11
4189858
СLАМР, РIРЕ
12
J011250
BOLT, SEMS
13
J011260
BOLT, SEMS
16A
4254436
HOSE
16B
4044420
PROTECTOR
17A
4285464
HOSE
17B
4044420
PROTECTOR
19
4138938
O-RING
78
4189602
ADAPTER, S
78A
4506418
O-RING
79
4138938
O-RING
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
