1
2
3
3
4
5
5
6
7
8
9
10
11
12
13
Позиция на иллюстрации
Заводской номер детали
Название детали
1
M115400100
SWING CARRIAGE ASSY
2
801/02058
PIN
3
801/02165
PIN
4
811/09042
PIN
5
811/09045
PIN
6
811/09058
PIN
7
M115400200
SWING CARRIAGE
8
N01/0380746
Bolt
9
N01/0380818
Bolt, Hex.
10
N02/5900086
Nut
11
N03/0810001
Washer
12
N08/1210020
Lubricants
13
N15/6451938
PIN, EXPANSION
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
