1
2
3
4
4
5
6
7
8
9
10
11
12
Позиция на иллюстрации
Заводской номер детали
Название детали
1
M114500300
AXLE, LONG
2
M114500600
AXLE, LONG
3
N01/0000218
BOLT
4
N09/0500350
BEARING
5
N10/8615181
SEAL, AXLE
6
N10/2032307
O-RING
7
M114500400
WHEEL HUB
8
M114500800
WASHER
9
M114500700
NUT, ADJUSTING
10
M114501400
SPROCKET
11
M114501500
STUD, AXLE
12
N02/8320300
NUT
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
