DECALS, WARNING
DECAL AND PLATES, MACHINE MODEL & INFORMATION
TOOL KIT
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
Позиция на иллюстрации
Заводской номер детали
Название детали
1
М117002800
DECAL, WARNING, AIR FILTER, TR
2
М117002700
DECAL, WARNING, AIR FILTER, ENGLISH
3
М117009400
DECAL, SEAT BELT
4
М117007700
DECAL, OPERATING AND MAINTENANCE MANUAL
5
М117007600
DECAL, BACKHOE WARNING, RIGHT
6
М117007500
DECAL, BACKHOE WARNING, LEFT
7
М117008600
DECAL,WARNING, STABILISER
8
М117002200
DECAL,ACCUMULATOR POWER SWITCH
9
Y06/11340
Decal, Electric Wn.
10
М117002500
DECAL,WARNING, FUEL
11
М117008300
DECAL, ENGINE WARNING
12
М117002300
DECAL, BATTERY
13
М117007400
DECAL, LOADER WARNING, RIGHT
14
М117007300
DECAL, LOADER WARNING, LEFT
15
М117008500
DECAL, MECHANISM WARNING
16
М117007200
DECAL, SAFETY STRUT
17
М117008400
DECAL, SAFETY WORKING LOAD
18
М117009500
DECAL, SEAT BELT
19
М117002600
DECAL,WARNING, FUEL
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
