Каталог запасных частей к технике: Hidromek HMK 300LC. ENGINE MOUNTING
1
2
3
4
4
5
5
5
5
6
6
7
7
7
7
8
8
8
8
9
9
10
10
11
12
12
12
12
13
13
13
13
14
15
16
16
17
17
18
18
19
19
20
20
21
21
24
25
26
27
28
29
30
31
32
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | H252000100 | Engine, 6D16 | |
| 2 | H252000200 | Bracket WA, Right, Front | |
| 3 | H252000800 | Bracket WA, Left, Front | |
| 4 | H252001100 | Bracket, Rear | |
| 5 | H252001200 | Cushion, Rear | |
| 6 | H252001300 | Sheet, Eng. RR Mount. | |
| 7 | H252001400 | Stopper, Eng. RR Mount | |
| 8 | H252001500 | Cushion, Front | |
| 9 | H252001600 | Washer, Pln. | |
| 10 | H252001700 | Stopper | |
| 11 | H342010200 | Fan | |
| 12 | N01/0232498 | Bolt, Hex. | |
| 13 | N03/1310011 | Washer, Spr. | |
| 14 | N01/0232858 | Bolt, Hex. | |
| 15 | N03/1310012 | Washer, Spr. | |
| 16 | N01/0381608 | Bolt, Hex. | |
| 17 | N02/3570338 | Nut, Hex. | |
| 18 | N03/1310032 | Washer, Spr. | |
| 19 | N01/0381920 | Bolt, Hex. | |
| 20 | N02/3570374 | Nut, Hex. | |
| 21 | N03/1310016 | Washer, Spr. | |
| 24 | H252002000 | Sheet, Fuse Mounting | |
| 25 | N01/0222438 | BOLT M10x20 | |
| 26 | N03/1310011 | Washer, Spr. | |
| 27 | N03/0020121 | Washer, Pln. | |
| 28 | N01/0222054 | BOLT M8x12 | |
| 29 | N03/1310010 | Washer, Spr. | |
| 30 | N03/0020111 | Washer, Pln. | |
| 31 | N01/1661862 | Bolt, Cylinder Head | |
| 32 | N03/0100011 | Washer, Pln. |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
