Каталог запасных частей к технике: Hidromek HMK 300LC. CAB (1)

Тип техники

Марка

Модель

Схема

H346000203

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

25_1

25_2

25_3

25_3

25_4

25_5

25_6

25_7

25_8

25_9

26

27

27

28

28

29

29

29

29

30

30

31

33

33

33

Позиция на иллюстрации	Заводской номер детали		Название детали
H346000203	H346000203		Cab Ass'y
1	H346020102		Cab, W.A.
2	H346047600		Weather Strip
3	H346046100		Sash, Front Glass
4	H346047300		Weather Strip, Glass
5	H346047400		Retaining Rub., Wtr Str
6	H346047701		Glass, Front
7	H346047500		Rubber
8	H346040900		Weather Strip, Glass
9	H346041000		Retaining Rub., Wtr Str
10	H346040800		Glass, R/H, Front
11	H346040600		Weather Strip, Glass
12	H346040700		Retaining Rub., Wtr Str
13	H346040500		Glass, R/H, Back
14	H346040300		Weather Strip, Glass
15	H346040400		Retaining Rub., Wtr Str
16	H346040200		Glass, Back
17	H346041200		Weather Strip, Glass
18	H346041300		Retaining Rub., Wtr Str
19	H346041100		Glass, L/H, Back
20	H346045600		Weather Strip, Glass
21	H346045700		Retaining Rub., Wtr Str
22	H346044900		Glass, Door, Bottom
23	H346044400		Weather Strip, Glass
24	H346044500		Retaining Rub., Wtr Str
25	H346044600		Sash Ass'y, Door
25_1	H346044701		Glass, Door
25_2	H346044801		Glass, Door
25_3	H346045500		Handle
25_4	H346063900		Weather Strip, Out., RR
25_5	H346063800		Weather Strip, In., FR
25_6	H346045900		Sash, Door Glass
25_7	H346064000		Weather Strip, Middle
25_8	H346064100		Weather Strip, Out.
25_9	H346064200		Weather Strip, In.
26	H346039400		Glass, Front, Bottom
27	H346039500		Con. Plate, Bot.Glass
28	N01/0000008		Bolt, Glass Conn.
29	810/40046		Washer, Pln., Rubber
30	N02/5900062		Washer, Pln.
31	N01/0222114		Bolt, Hex.
33	814/00155		Cover, Bolt

Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
