Каталог запасных частей к технике: Hidromek HMK 230LC3. CAB ACCESSORIES

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
3
4
5
6
7
10
10
10-1
10-1
10-2
10-2
10-3
10-3
10-4
10-4
10-5
10-5
10-5
10-6
10-6
10-6
10-7
10-7
10-7
10-8
17
26
29
36
39
53
54
56
58
58
63
65
67
75
75
76
76
80
80
80
81
81-1
81-2
81-3
81-4
81-4-1
81-4-2
81-4-3
81-5
81-6
82
82-1
82-2
82-3
87
88
94
96
97
98
99
100
101
102
103
104
108
113
114
117
118
118
119
119
120
121
122
123
124
125
126
126
127
127
128
129
129
130
131
132
132
10
10
10-1
10-1
10-2
10-2
10-3
10-3
10-4
10-4
10-5
10-5
10-5
10-6
10-6
10-6
10-7
10-7
10-7
10-8
Позиция на иллюстрации Заводской номер детали Название детали
3 M116001100 ARM, MIRROR
4 H907002600 DECAL
5 H906239600 BRACKET W.A.
6 N049602042 SCREW
7 H900519100 FIRE EXTINGUISHER
10 H906572400 SUNROOF ASSY
10-1 H906572100 SUNROOF W.A.
10-2 H906535200 GLASS
10-3 H906033700 LOCK
10-4 N015890290 BOLT
10-5 H906570000 GAS SPRING
10-6 N025900050 BOLT
10-7 N030020006 WASHER
10-8 02040684 ISOLATION SPONGE
17 H906215500 BRACKET
26 H906512600 CURTAIN
29 H906274500 TRIM, UPPER
36 H906292900 HANDLE
39 H906242800 WEATHER STRIP
53 N010222120 BOLT
54 H906276400 DECAL
56 N010232822 BOLT
58 N015870446 BOLT
63 N030140017 WASHER
65 N030100023 WASHER
67 N030140017 WASHER
75 N049560844 SCREW
76 N030100013 WASHER
80 N049560848 SCREW
81 H906056001 WIPER
81-1 H909060001A MOTOR, ELECTRICAL
81-2 H909060002 LINK
81-3 H909060003 ARM
81-4 H909060004 WIPER BLADE
81-4-1 H909060005 WIPER BLADE
81-4-2 H909060006 WIPER BLADE
81-4-3 H909060007 BRACKET
81-5 H909060008 FITTING, ELBOW
81-6 H909060009 COVER
82 H906051000 BRACKET
82-1 H906051100 BRACKET
82-2 H906051200 BRACKET
82-3 N015870314 BOLT
87 N015870314 BOLT
88 N030100017 WASHER
94 S9100975 MIRROR
96 H906239000 ISOLATION SPONGE
97 H906116401 TRIM, RIGHT
98 H906105701 COVER
99 N044720662 SCREW
100 H906245200 CURTAIN
101 N049561284 BOLT
102 H906241200 CURTAIN, FRONT
103 N015870158 SCREW
104 H906239300 PLATE
108 H906254300 EMERGENCY HAMMER
113 H906242600 BRACKET
114 N049530362 SCREW
117 H906253100 HOSE
118 H906255700 HOSE
119 F3210568 CHECK VALVE
120 H906268900 CURTAIN
121 N044720662 SCREW
122 H906269400 ISOLATION SPONGE
123 H906269500 ISOLATION SPONGE
124 H906269600 ISOLATION SPONGE
125 H906269700 ISOLATION SPONGE
126 H906571200 BRACKET
127 H906142200 STOPPER
128 H906142000 STOPPER
129 N044720661 SCREW
130 N043700926 SCREW
131 N049601862 SCREW
132 N043700952 SCREW
10 H906572400 SUNROOF ASSY
10-1 H906572100 SUNROOF W.A.
10-2 H906535200 GLASS
10-3 H906033700 LOCK
10-4 N015890290 BOLT
10-5 H906570000 GAS SPRING
10-6 N025900050 BOLT
10-7 N030020006 WASHER
10-8 02040684 ISOLATION SPONGE
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
