Каталог запасных частей к технике: Hidromek HMK 220LC-2. WATER PUMP AND FAN MOUNTING
10000A
10001B
10001B
10001C
10001C
10010
10012
10016
10025
10025
10040
10043
10043
10044
10044
10051
10071
10071
10078
10088B
10088C
10096
10098
10534
10547
10547
10547
10589
10592B
10594
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 10000A | H349003600 | Water Pump Ass'y | |
| 10001B | H349003601 | Being, Water Pump | |
| 10001C | H349003602 | Being, Water Pump | |
| 10010 | H349003603 | Water Pump KIT | |
| 10012 | H349003604 | Case, Water Pump | |
| 10016 | H349003605 | Flange, Pulley Drive | |
| 10025 | H349003606 | Impeller | |
| 10040 | H349003002 | Belt, Alternator-Others | |
| 10043 | H349003608 | Seal Unit, Pump Shaft | |
| 10044 | H349003609 | Shaft, Water Pump | |
| 10051 | H349003610 | Thrust Washer, P. INR | |
| 10071 | H349003611 | O-Ring, Water Pump | |
| 10078 | H349003612 | Nipple, Pump INR | |
| 10088B | H349003076 | Bolt | |
| 10088C | H349003221 | Bolt | |
| 10096 | H349003615 | Spacer, Water P. INR | |
| 10098 | H349003616 | Snap Ring | |
| 10534 | H349003617 | Pulley, Fan | |
| 10547 | H349003618 | Spacer, Fan | |
| 10547 | H349003619 | Spacer, Fan | |
| 10589 | H349003620 | Stud, Fan | |
| 10592B | H349003621 | Bolt, Fan | |
| 10594 | H349003281 | Nut |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
