Каталог запасных частей к технике: Hidromek HMK 220LC-2. PISTON - CONNROD - CRANKSHAFT
03006
03010A
03010A
03010A
03010A
03010A
03010A
03016
03021
03036
03037
03037
03037
03047
03047B
03050
03050
03050
03050
03050
03060
03060
03060
03772
03785
03787
03788
03789
03791
03798
03798
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 03006 | H349003089 | Bolt, Connrod | |
| 03010A | H349003090 | Connecting Rod Ass'y | |
| 03010A | H349003091 | Connecting Rod Ass'y | |
| 03010A | H349003092 | Connecting Rod Ass'y | |
| 03010A | H349003093 | Connecting Rod Ass'y | |
| 03010A | H349003094 | Connecting Rod Ass'y | |
| 03010A | H349003095 | Connecting Rod Ass'y | |
| 03016 | H349003096 | Bushing, Connrod | |
| 03021 | H349003097 | Cone, Crnks. Pulley | |
| 03036 | H349003098 | Pin, Piston | |
| 03037 | H349003099 | Piston | |
| 03037 | H349003100 | Piston | |
| 03037 | H349003101 | Piston | |
| 03047 | H349003102 | Pulley, Crankshaft | |
| 03047B | H349003103 | Pulley, Crankshaft | |
| 03050 | H349003104 | Being , Connrod | |
| 03050 | H349003105 | Being , Connrod | |
| 03050 | H349003106 | Being , Connrod | |
| 03050 | H349003107 | Being , Connrod | |
| 03050 | H349003108 | Being , Connrod | |
| 03060 | H349003109 | Ring , Piston | |
| 03060 | H349003110 | Ring , Piston | |
| 03060 | H349003111 | Ring , Piston | |
| 03772 | H349003112 | Pin, Connrod | |
| 03785 | H349003113 | Nut, Cranks. Pulley | |
| 03787 | H349003114 | Bolt, Cranks. Pulley | |
| 03788 | H349003115 | Pin, Crankshaft | |
| 03789 | H349003116 | Key, Camshaft | |
| 03791 | H349003117 | O-Ring, Cranks. Pull. | |
| 03798 | H349003118 | Snap Ring, Piston |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
