Каталог запасных частей к технике: Hidromek HMK 220LC-2. MAIN PIPING MOUNTING (L/H)
21
22
23
24
25
35
36
37
37
38
39
39
40
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 21 | N16/K114345 | Connector | |
| 22 | N10/2002835 | O-Ring | |
| 23 | N01/5890830 | Bolt, Cyl. Hd. | |
| 24 | N03/1360010 | Washer, Spr. | |
| 25 | N10/2003335 | O-Ring | |
| 35 | H343000900 | Hose Ass'y | |
| 36 | H343001001 | Hose Ass'y | |
| 37 | N16/J360104 | Flange | |
| 38 | N10/2003335 | O-Ring | |
| 39 | N01/5890830 | Bolt, Cyl. Hd. | |
| 40 | N03/1360010 | Washer, Spr. | |
| 41 | H343001101 | Hose Ass'y | |
| 42 | H343001301 | Hose Ass'y | |
| 43 | N16/J320102 | Flange, Split | |
| 44 | N10/2002435 | O-Ring | |
| 45 | N01/5890830 | Bolt, Cyl. Hd. | |
| 46 | N03/1360010 | Washer, Spr. | |
| 47 | 99N095208 | Hose Ass'y | |
| 48 | N16/N910005 | Elbow | |
| 49 | N10/2002835 | O-Ring | |
| 50 | H343001500 | Hose Ass'y | |
| 51 | H343001600 | Hose Ass'y | |
| 52 | H343005700 | Clamp | |
| 53 | N01/0381238 | Bolt, Hex. | |
| 54 | N03/1310014 | Washer, Spr. |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
