Каталог запасных частей к технике: Hidromek HMK 220LC-2. DECAL MOUNTING (ENGLISH)

Тип техники

Марка

Модель

Схема

1

2

3

4

5

6

7

8

9

10

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

43

44

44

45

46

47

Позиция на иллюстрации	Заводской номер детали		Название детали
1	H347000203		Decal, Model
2	H347000500		Emergency Exit
3	H347010700		Track Adjuster
4	H347000800		Keep Away, L/H
5	H347000900		Keep Away, R/H
6	Y06/11340		Decal, Electric Wn.
7	H347011101		Name Plate
8	H347011200		Fuel Decal
9	H347001301		Anti Skid Strip
10	H347001401		Anti Skid Strip
11	H347011500		Decal, Hyd. Oil
12	H347011600		Wning Decal
13	H347011700		Wning Decal
14	H347011800		Accum. Wn. Decal
15	H347001900		Master Switch On/Off
16	H347012000		Before Operating
17	H347012100		Wning Decal
18	H347012200		Wning Decal
19	H347012300		Decal, Safe Operation
20	H347002400		Decal, Operation
21	H347012500		Decal, Air Bleeding
22	H347012600		Decal, Throttle Cable
23	H347035100		Decal, Inspection
24	H347035200		Decal, Tech. Specific.
25	H347012900		Wning Decal, Hot
26	H347013001		Decal, Air Filter
27	H347013100		Reservoir Tank, Wn.
28	H347013200		Decal, Safety Lock.
29	H347013300		Wning Decal
30	H347013500		Decal, Hyd. Oil Level
31	H257013603		Decal, Fuse
32	H347003800		Decal, Auto-Manuel
33	H347003900		Decal, Reflector
34	H347004000		Decal, Reflector
35	H347005303		Decal, Hyd. Tank
36	H347004703		Decal, Tool Box
37	H347004803		Decal, Cab Door
38	H347004903		Decal, Accum. Box
39	H347005101		Decal, Logo
40	H347030500		Decal, Fuel Tank
41	H347000600		Decal, Attachment
42	H347010400		Decal, Lifting Capacity
43	H347006000		Anti Skid Strip
44	H347006100		Anti Skid Strip
45	H347006200		Anti Skid Strip
46	H347030300		Sound Level, Outside
47	H347030400		Sound Level, Inside

Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
