Каталог запасных частей к технике: Hidromek HMK 200W. POWER TRAIN HYDRAULIC MOUNTING
15
16
17
21
22
23
24
25
33
34
35
36
38
39
39
40
86
87
88
89
90
91
94
94
95
95
96
97
98
99
100
101
102
104
105
106
107
108
109
110
111
112
113
129
130
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 15 | N03/0000015 | Washer | |
| 16 | N16/K520107 | Connector | |
| 17 | N10/2001322 | O-Ring | |
| 21 | H343202600 | Block, Accumulator | |
| 22 | N01/0370650 | Bolt, Hex. | |
| 23 | N03/1310011 | Washer, Spr. | |
| 24 | N16/K114341 | Connector | |
| 25 | N10/2001024 | O-Ring | |
| 33 | N16/K114343 | Connector | |
| 34 | N10/2001724 | O-Ring | |
| 35 | N16/K114341 | Connector | |
| 36 | N10/2001024 | O-Ring | |
| 38 | N16/K114342 | Connector | |
| 39 | N10/2001322 | O-Ring | |
| 40 | N16/K114348 | Connector | |
| 86 | N16/K114354 | Connector | |
| 87 | N10/2001724 | O-Ring | |
| 88 | 97S091267 | Hose Assy | |
| 89 | N16/K114341 | Connector | |
| 90 | N10/2001024 | O-Ring | |
| 91 | 97S091267 | Hose Assy | |
| 94 | N16/K114342 | Connector | |
| 95 | N10/2001322 | O-Ring | |
| 96 | 99S092269 | Hose Assy | |
| 97 | 99U092268 | Hose Assy | |
| 98 | H343202501 | Accumulator | |
| 99 | 97Q091205 | Hose Assy | |
| 100 | N16/K114343 | Connector | |
| 101 | N10/2001724 | O-Ring | |
| 102 | 99Q093243 | Hose Assy | |
| 104 | H233521100 | Press. Relief Valve | |
| 105 | H233521400 | Bracket | |
| 106 | N16/K114343 | Connector | |
| 107 | N10/2001724 | O-Ring | |
| 108 | 99U093225 | Hose Assy | |
| 109 | N16/K114343 | Connector | |
| 110 | N10/2001724 | O-Ring | |
| 111 | H233521200 | Check Valve | |
| 112 | N01/0370446 | Bolt, Hex. | |
| 113 | N03/0140017 | Washer, Spr. | |
| 129 | N01/0380290 | Bolt, Hex. | |
| 130 | N03/1310008 | Washer, Spr. |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
